Product details

Ductile iron bar is a type of iron that has been treated with magnesium to make it more flexible and less brittle. It is also known as nodular cast iron or spheroidal graphite iron. Ductile iron bars are used in a variety of applications, including construction, automotive manufacturing, and agriculture. They are known for their high strength, durability, and resistance to wear and corrosion. Ductile iron bars are also easy to machine and weld, making them a popular choice for many industrial applications.

This material offers excellent strength, toughness, and wear resistance, making it ideal for applications in the automotive, construction, and agricultural industries. Rectangular bars are stocked in a range of sizes, from 1.250” x 2.000” to 14.000” x 24.000”. Standard lengths are 72”, while additional lengths are available up to 144”. Industrial Tube & Steel Corporation is committed to providing high-quality ductile iron rectangular bar to meet the needs of our customers. Contact us today to learn more about our inventory and services.

Gray Iron Round Bar is stocked in an assortment of diameters, from 0.625” to 26.560”. As-cast round bars are made to clean up to the nominal size. Additional stock is added to allow for out-of-round and normal imperfections in the as-cast surface. For applications with demanding tolerances, centerless grinding and turning services are available. Standard bar lengths are 72", but we can supply them in lengths up to 144”.

Upon request, Industrial Tube & Steel can supply Gray Iron Round Bar at custom lengths. Our industry-leading automatic sawing equipment allows us to cut raw material to any specified dimension quickly and precisely.

Industrial Tube & Steel carries a wide selection of Gray Iron Round Bars to suit any application. This material is produced to meet ASTM A48, Class 40 specification standards,

Curb the cost of manufacturing parts by reducing machining time and extending tool life with ductile iron square bar. This material is comparable in strength to plain carbon and free-machining steels, but it offers improved machinability at a lower overall cost.

Ductile iron square bar is stocked in a range of sizes, from 2.030” x 2.030” to 21.000” x 21.000”. As-cast squares are made to the actual size with no allowance for machine stock added. Squares are cast to actual dimension, with clean up stock dependent on the height-and-width ratio. They can be milled to achieve close-tolerance benefits, upon request. Standard lengths are 72”, while additional lengths are available up to 144”.

Industrial Tube & Steel Corporation is ready and willing to answer any of your cast iron size, tolerance, or length needs. Our industry-leading automatic equipment enables us to cut raw material to your specific dimensions quickly and efficiently.

As-cast rectangles are made to the actual size with no allowance for machine stock added. They are cast to actual dimension, with clean up stock dependent on the height-and-width ratio.

Industrial Tube & Steel carries a vast inventory of ductile iron rectangular bar to suit any application. This material is produced to meet ASTM A536 specification standards, and is available in the following grades:

65-45-12
80-55-06
100-70-03

65-45-12 grade ductile iron contains nodular graphite in a matrix of ferrite with small amounts of pearlite. The ferritic structure gives excellent machinability with good surface finishes along with optimal impact strengths, fatigue properties, electrical conductivity, and high magnetic permeability. This iron has approximately the same tensile and yield strengths as AISI 1020 steel in the as-rolled condition.

80-55-06 grade ductile iron contains nodular graphite in a matrix of ferrite and pearlite. The pearlite-and-ferrite structure provides higher wear resistance and strength when compared to a ferritic grade of ductile iron. This material is readily machinable and displays good surface finishes. Tensile and yield strengths are similar to AISI 1040 steel in the as-rolled condition.

100-70-03 ductile iron combines nodular graphite in a matrix of pearlite with a small amount of ferrite. It's produced in a range of sizes and shapes and is often used in place of plain carbon steel. Its machinability is similar to carbon steel.

Grey cast iron
GB National Standard:	HT100, HT150, HT200, HT250, HT300, HT350
JIS Japan	FC100, FC150, FC200, FC250, FC300, FC350
KS Korea	GC100, GC150, GC200, GC250, GC300, GC350
AWS USA	NO.20, NO.25, NO.30, NO.35, NO.40, NO.45, NO.50, NO.55, NO.60
UNS United States	F11401, F11701, F12101, F12801, F13101, F14101
Ductile iron
GB China	QT400-18, QT400-15, QT450-10, QT500-7, QT600-3, QT700-2, QT800-2 QT900-2
JIS Japan	FCD350-22, FCD400-18, FCD400-15, FCD450-10, FCD500-7, FCD600-3 FCD700-2, FCD800-2
KS Korea	GCD370, GCD400, GCD450, GCD500, GCD600, GCD700, GCD800
AWS US	60-40-18, 65-45-12, 80-55-06, 100-70-03, 120-90-02
UNS US	F32800, F33100, F33800, F34800, F36200
