Product details

Round and Oval Feeder Bottle Screen Printing Machine


Machine Parameters:

Output Up to 50pcs/min
Work Stations 10
Printing Colors 3
Printing Diameter at 360 Degree 13-80mm
Bottle Height 25-250mm
Max Printing Length 200mm
Max Printing Height 120mm
Machine Dimension L3500XW2300XH2200mm
Power AC220V 50HZ 40KW
Air


Process Flow:

  • Manually laying the bottle on the conveyor belt
  • The bottle reaches the feed preset position
  • Manipulator puts the bottle into the turntable fixture
  • Product surface plasma treating
  • Product CCD positioning(cycle)
  • Screen printing(1st color)
  • Hot wind surface curing(1st color)
  • Screen printing(2nd color)
  • Hot wind surface curing(2nd color)
  • CCD inspection for printed products
  • Diversion of unqualified products
  • Standing discharging
  • The bottles are lined up and sent into the oven by manipulator
  • The bottle is fully cured in an oven up to 120℃ in 8 minutes
  • Finished products


We Senny Printing Equipment manufactures full servo screen printing machine and full servo hot stamping machine in China. Our Automatic Screen Printer and Automatic Hot Stamping Machine can print various shapes on plastic, glass and metal etc.materials. Our screen printing machines are popular in the cosmetics packaging industry, wine bottle printing industry, beauty industry, and food packaging industry etc.
