Production Description

Product Parameter

Main Specification	Unit	Parameter
Capacity	Ton	45
Stroke	mm	20	30	40
Stroke Per Minute	S.P.M	200-800	200-700	200-600
Die-Hight	mm	215-245	210-240	205-235
Slide Adjustment	mm	30
Slide Area	mm	42032065
Bolster Area	mm	680440100
Bed Opening	mm	400*100
Main Motor	HP	7.5
Presses Dimension	mm	142011002510
Presses Precision		GB(JIS) 1 Class

Product Advantages:

1.Advanced industrial design ideas, low noise, low consumption, and good saving energy.

2. Adoption of high-strength cast iron, which's more resistant to minimal vibration, ensuring stamping accuracy and the service long-life.

3. Microcomputer controls system and few peripheral electrical elements with high stability. Operator can disassemble the board of the press, which is easy for maintenance.

4. Hydraulic overload protector with clutch brake is equiped as a standard feature to cause emergency stop instantly , that can greatly ensure maximum protection for the press and die.

5. Using oil lubracation system introduced MPA from USA, which's fully ensuring the high-speed lubrication requirements,reduce oil leakage of the press and remain the cleaness of the press.

6. American MAC low voltage solenoid valve, low temperature rise, low noise, speed accurate to 12000 times per minute.

7. Adopt Air filtrate system from Taiwan Duplex pieces, the water in the air filter out, to ensure that the gas parts of the press dry and prolong the life.

Punch Press C-Type High-Performance Stamping Presses 45t Mechanical Punching Machine High Speed Power Press for Cooling Fin of Solar Water Heater Punching

Punch Press C-Type High-Performance Stamping Presses 45t Mechanical Punching Machine High Speed Power Press for Cooling Fin of Solar Water Heater Punching

Where places is suitable for applicating of the heat sink stamping parts?

1.Computer fileds: computer mainboard, PC, IPC, Server, PCTV, Router, Power supply (CPU cooler, VGA cooler, Cooling fan).

2. Machines: Industry/Medical/Auto Spare Parts/Household Appliances etc.

3. LED lighting: stage light, high bay light, down light, street light, automobile lamp ,etc.

4. Security fields: security cameras, infrared light cameras.

5. Home appliances: pico projector, electronic refrigerator, red wine cooler, LASER TV, LCD TV, LED panel, Sound, Air condition, induction cooker, etc.
Punch Press C-Type High-Performance Stamping Presses 45t Mechanical Punching Machine High Speed Power Press for Cooling Fin of Solar Water Heater Punching

Q1:Are you a trading company or manufacturer?
A1: We are a manufacturer more than 17 years.

Q2:Can you help me solve a whole stamping line?
A2: Yes, please provide the product drawings, and then we'll give you a best project.

Q3:How long does the general lead time take?
A3:All machines need to be arranged for production, which shall be determined to the situation at that time.

Punch Press C-Type High-Performance Stamping Presses 45t Mechanical Punching Machine High Speed Power Press for Cooling Fin of Solar Water Heater Punching
