UN33 10-60kva three phase online UPS

2 year ago

24 0

Shenzhen Unitronic Power System Co., Ltd

 3 year year

Product details

UN33 series 10KVA/10KW, 15KVA/15KW, 20KVA/20KW, 30KVA/30KW, 40KVA/40KW, 60KVA/60KWis three phase online UPS of which 10-30KVA can be installed built-in battery. This tower online UPS series adopts DSP control technology and online double conversion technology, which can completely eliminate various grid problems and provide customers with stable and pure sinusoidal power protection. The advanced design makes these products have unparalleled reliability and high performance. High input power factor (pf > 0.99) and low input harmonic distortion (THDi < 3%) ensure that UPS is green and environmentally friendly and high efficiency, which ensures energy saving.

◆Application

Small and medium-sized data centers, IT machine rooms, financial institutions, traffic dispatch centers, security monitoring, etc.

◆Features

●Wide input voltage range

●Online double conversion technology

●DSP digital control technology

●Intelligent battery management extends battery life

●High efficiency, up to 95%

●4.3-inch color touching screen, friendly man-machine interface, easy to operate

●Parallel up to 8 units

Model		UN33010KS	UN33015KS	UN33020KS	UN33030KS	UN33040KS	UN33060KS
		UN33010KL	UN33015KL	UN33020KL	UN33030KL	UN33040KL	UN33060KL
Capacity		10kVA	15kVA	20kVA	30kVA	40kVA	60kVA
Input	Phase	3 Phase+Neutral+Ground
	Rated Voltage	380/400/415Vac
	Voltage Range	208-478Vac
	Frequency Range	40-70Hz
	Power Factor	≥0.99
	THDi	≤3% (100% linear load)
Bypass	Voltage Range	Upper limit: 380V+25% (+10%, +15%, +20%, settable); 400V+20% (+10%, +15%, settable) 415V+15% (+10%, settable); Lower limit: -45% (-10%, -20%, -30%, settable)
	Frequency Range	50/60Hz±10%
Output	Phase	3 Phase+Neutral+Ground
	Rated Voltage	380/400/415Vac
	Power Factor	1
	Voltage Regulation	±1%
	Output Frequency	Normal Mode: ±1%/±2%/±4%/±5%/±10%, settable; Battery Mode: 50/60Hz±0.1%
	Crest Factor	3:1
	THDu	≤2% ( linear load); ≤4% (non-linear load)
	Overload	110% for 60 mins; 125% for 10 mins; 150% for 1 min; ＞150%, transfer to bypass
Battery	Rated Voltage	±240VDC
	Quantity	12V/9Ah *40 pcs					12V/9Ah*40 pcs
		External
	Charging Current	1A					2A
		1-10A					1-15A
System	Efficiency	96%
	Display	4.3-inch color touching screen
	IP Class	IP20
	Interface	USB, CAN, RS485, LBS, Parallel card (optional), Relay card (optional), SNMP card (optional)
	Temperature	Operation: 0-40℃; Storage: -25-55℃
	Humidity	0-95% (non-condensing)
	Altitude	＜1500m, within 1500-4000m, power derates 1% every 100m rise
	Noise	＜58dB
	Applicable Standard	Safety: IEC/EN 62040-1; EMC: IEC/EN 62040-2; Performance: IEC/EN 62040-3
Physical	Weight	147	148	155	158	165	184
		44	45	52	55	62	80
	Dimension DWH (mm)	280774719					330900980
