This 12V380W(100A) UPS battery High Rate Sealed Lead Acid Rechargeable Battery is part of our UNH range of sealed lead acid batteries. The 12V UNH series high rate VRLA batteries are specially designed for UPS systems,data centers and electrical systems. The UNH series high rate batteries are based on AGM technology. These batteries are made of a special corrosion resistant alloy and thinner sheet which make them have a larger plate surface area than ordinary batteries. Based on the advanced technology, the UNH heigh rate batteries can deliver high power pulses for short time periods.
This 12V 100Ah AGM High Rate Sealed Lead Acid Rechargeable Battery can reach 380 watts while working. It is an ideal choice for high efficient discharge applications such as such a Office Machines and Computers,Telecommunications UPS Equipment,etc. This battery can deliver consistent backup power for UPS and critical power applications such as file alarms,emergency lighting,security cameras,network servers,IT systems and process control systems. With excellent high power discharge performance and high reliability,our high rate batteries are perfect for these applications due to their low cost,low maintenance and reliability in float mode.
Product Information:
| Nominal Voltage(@25℃): | 12V |
| 15 Minute rate Capacity (@25℃): | 380W |
| Weight: | 31kg (68.342lbs) |
| Length: | 328mm (12.913inches) |
| Width: | 171m (6.732inches) |
| Height: | 214mm (8.425inches) |
| Total Height: | 218mm (8.583inches) |
| Terminal: | F11 OR F12 |
| Design life(@25℃) | 10-12 years |
| Warranty: | 24 months |
| Certificate: | ISO9001, ISO14001, ISO45001, UL, CE, TLC |
| Package: | 1 pcs per Carton |
Features of this 12V 100Ah AGM High Rate Sealed Lead Acid Rechargeable Battery:
• 380w high rate battery ideal for UPS Equipment,Office Machines and Computers,Telecommunications,etc
• Sealed Lead Acid Rechargeable SLA AGM Battery for UPS Systems, Servers, Backup Power
• Pure heavy-duty lead calcium grid design
• Positive and negative plates with lead calcium alloy
• Tank formed plates for even capacity matched plates
• Anchored plate groups to guard against vibration
• Superior energy density
• Low pressure operating flame arresting safety valves
• 99% Internal gas recombination
• Usable in any orientation
• General purpose electric vehicle application
• Low self discharge, six months shelf life @ 20 C
• Improved cycle life design
• Complies with IATA/ICAO Provision A67
• Classed as non-spillable, not restricted for air transport
• Multi-terminal options available on special on special order
• Removable carry handles on most blocks
Typical Applications of this 12V 100Ah AGM High Rate Sealed Lead Acid Rechargeable Battery:
• Office Machines and Computers
• Telecommunications
• UPS Equipment
• Electrical facilities
• Vending machine
FAQ
1, What is a high rate battery?
High rate batteries are made specifically to deliver high power pulses for short time periods. In most batteries, such as lead-acid and Absorbent Glass Mat (AGM), there is a correlation between the depth of discharge (DOD) and the cycle life of the battery. Cycle life of a battery is the number of charge/discharge cycles it can sustain in its life and depends on the DOD that is allowed. If the discharge of the battery is kept to a lower percentage (approximately 50%), it will have more useful cycles than if it is frequently discharged to its maximum DOD (below 80%).
The typical lead-acid battery provides 200-300 charge/discharge cycles depending on the operating temperature and DOD. High rate batteries can perform up to 400 charge/discharge cycles when operating at 68-77 degrees Fahrenheit at a 50% DOD with a 14-16 year life.
2,What are high discharge battery applications?
High discharge batteries are usually used for industrial and consumer applications like UPS systems,IT systems,RC models,drones,robotics and vehicle jump starters. All these applications require a powerful energy burst in a short period of time.
