Product details

Rotary arm stretch wrapper operate by placing under the so called rotating arm. The machine arm including the carriage submitting the film revolves ones the start button is pushed and LLDPE Stretch-film is wrapped around the pallet as it rotates.

Pallet stretch wrap machines with rotary arm are in specific used in case of instable, light pallets, or pallets which are tending to collapse while rotating on a standard turntable.

Stretch uniquely guarantees the user:

Easy installation
Reduced operating space
Low maintenance costs.
Robust, durable and reliable machines

Consumables are made from LLDPE Stretch-film and automatic rolls are available on the market in different thicknesses and qualities. Use of our machines with high quality film, enables significant savings in operational costs.

A brief introduction to our SEMI-AUTOMATIC rotating arm machines

(The number of pallets wrapped are an indication for an 8-hour shift, with pre-selected parameters such as average pallet height 2.000mm incl two bottom and two top-wraps. The info is provided as a general guideline, to help you choose the machine which best suits your wrapping requirements. no rights may be derived from the indications provided)

LYBRA EASY
Machine is supplied with 3 + 1 programs and comes equipped with mechanical brake type film carriage system. It has various options available, including a magnetic (FE) brake type film carriage and some variation in pallet dimensions and heights.
For the infrequent user, wrapping a moderate number of pallets per day (>15 <30 Pallets)

LYBRA
Machine supplied with Max 99 programs, as standard it is equipped with a mechanical brake system with the option to select a film carriage from FE, PRS or PS Power Pre-Stretch systems. Film carriage upgrades can also be retrofitted by means of a simple change and upgrade system, should you find your requirements change in the future. This model can manage a large variation in pallet dimensions and heights. It also has the flexibility to add a range of options and interesting functions to the standard operating panel.

Unlike its competitors, the arm is by gear and not by chain – this has the result of a more sturdy construction, less subject to wear and kickbacks.
The edge of the rotary arm has a shock sensor; thereby anyone on the path of the arm is protected against the risk of accidental impacts.
For the specialised user, wrapping a large number of pallets per day (>15 <100 Pallets)

LYBRA AUTO
Machine supplied with Max 99 programs and as standard is equipped with a magnetic brake system. Various options such as FE, PRS or PS Power Pre-Stretch systems are also available.
The machine is a standalone semiautomatic – automatic wrapper with cutting and clamping system, providing simple operation and reliability. The edge of the rotary arm has a shock sensor; thereby anyone on the path of the arm is protected against the risk of accidental impacts.

A brief introduction to our AUTOMATIC rotating arm machines

LYBRA STATION
Machine supplied with Max 99 programs, and as standard is equipped with a magnetic brake system. It can be supplied with 90mm high, IN and OUT feed conveyor systems with loading capability for Forklift trucks or if required pallet lifters and manual trans pallets. This is a highly economical solution.
For the business user, wrapping a large number of pallets per day (>64 <200 Pallets)

REVOLUTION LS
Machine supplied with multiple programs, Siemens PLC and Profase HMI. As standard it is equipped with a magnetic brake system (options available). It can be supplied with a 550mm high, IN and OUT feed conveyor system with loading capability for Forklift trucks or if required pallet lifters. Installed in a transport line, the machine does not need the intervention of the operator unless for changing the reels.
This is the industrial solution for businesses requiring the most inexpensive way to wrap between 280 and 470 Pallets per shift.

REVOLUTION HS
This is the industrial solution for businesses requiring the most inexpensive way to wrap between 280 and 500 Pallets per shift.

REVOLUTION HD
This is the industrial solution for businesses requiring the most inexpensive way to wrap between 400 and 560 Pallets per shift.

REVOLUTION DOUBLE
This is the patented version of the family REVOLUTION machines. The TWO carriages mounted on the same rotating arm, enables the user to cover 900mm of the pallet with each and every wrap. Having the advantage of TWO carriages provides the possibility to use only one cutting and clamping system, [less wear and tear" and enables him to change the empty cores from one side of the conveying system, without dangerous trespassing. Or in an even worst situation being forced to walk around to the other side of the wrapping system.

Stretch provides [one" entry and [one" safe operating position from which the operator can do the job, in a reduced time.

With such speed the required intervention of the engineer is minimal one time per hour. Spending too much time on complicated coil changing systems will effect the total output of the machine during the operating shift.
