Cementing Head for Well Cementation

As a cementing tools and Accessories manufacturer and supplier,we design and manufacture custom cementing heads and tools for the oil and gas in competitive price.A wide variety of cement head options are available to you, such as carbon steel, stainless steel, and high manganese steel. You can also choose from api, aisi, and astm. As well as from drilling tool, drilling equipment, and crusher. And whether cement head is well drilling, or ore mining. Cement head products are most popular in Russian Market, North America, and Southeast Asia.

Cementing head is a kind of special tool to pump slurry and release plug. It is used to fill drilling fluid into casing in turn and quickly. In most operations, a bottom plug is launched before the spacer or cement slurry. The top plug is released from the cement head after the spacer fluid. Most cement heads can hold both the top and bottom plugs. A manifold incorporated into the cement head assembly allows connection of a fluid circulation line.

We offers 5 types of cement head products:Double plug cement head,Single Plug Cement Head,High Pressure Cement Head,Casing Cement Head,Top Drive Casing Cement Head.

The Double Plug Cement Head is a wellhead equipment.It has two plug containers and it is used for double plug cementing and two stage cementing operation.Double Plug Cement Head is a special tool for grouting cement and releasing rubber plugs. Two rubber plugs can be installed at the same time, which can be used for both conventional double plug cementing and continuous two-stage cementing.
Double plug cementing head

Specifications (in)	5 1/2"	7"	7 5/8"	9 5/8"	10 3/4"	13 3/8"
Overall Length (mm)	1950	2020	2360	2360	2440	1780
Manifold	2" 1502 Union
ID of Plug Container (mm)	Φ125	Φ175	Φ225	Φ250	Φ320	ø 320
Length of Plug Container (mm)	400	450	550	550	600	600
Working Pressure (Mpa)	35.50	35.50	35.50	35.50	35	21

The single plug cement head is special cementing equipment for pumping slurry and releasing plug and can be connected with casing.Quick-install connector available for easy installation.Internal-balance design and the plunger can be opened easily.

Single plug cementing head

Specifications (in)	5 1/2"	6 5/8"	7"	7 5/8"	9 5/8"	10 3/4"	13 3/8"
Overall Length (mm)	1460	1500	1500	1550	1750	1750	1780
Manifold	2" Union
ID of Plug Container (mm)	ø125	ø 150	ø 160	ø 175	ø 225	ø 250	ø 320
Length of Plug Container(mm)	400	450	450	450	550	550	600
Working Pressure (Mpa)	35.50	35.50	35.50	35.50	35.50	35	35

The ultra high pressure cement head is a kind of double plug cementing cement head designed by our company for ultra-deep wells and high-pressure wells. It can be widely used in deep well cementing and shale gas cementing fields.

The cement head is not welded as a whole, and the joints of the parts are all designed with threaded connection + sealing ring.Equipped with a rubber plug indicator to facilitate the operator to know whether the rubber plug is down and a large pitch quick connection device, which can realize the quick installation and disassembly of the cement head.

Working Pressure
　　2 7/8″ – 7″ 10,000 PSI / 70 Mpa 7 5/8″ – 9 5/8″ 7500 PSI 10 3/4″ – 13 3/8″ 5000 PSI 16″ – 20″ 3000 PSI

Types	Width	Height	Plug Space	O.D.	I.D.	Crossover I.D.	Weight/LBS
4 1/2″	38	67	13	7	4.5	3.9	1115
5 1/2″	39	67	13	7.3	5.5	4.7	1240
6 5/8″	41	67	13	9.3	6.6	5.7	1490
7″	41	67	13	9.3	7	5.9	1500
7 5/8″	42	67	13	9.5	7.6	6.7	1500
9 5/8″	44	68	13	11.5	9.6	8.5	1665
10 3/4″	45	71	15	13.5	10.8	9.8	1910
13 3/8″	48	73	16	16.5	13.4	12.3	2570
16″	50	81	20	18.5	16	15	2090
18 5/8″	53	85	22	20.8	18.6	17.8	3095
20″	55	89	24	22.5	20	18.7	3610

The casing cement head with double plugs (called as cement-head ) is a common cementing tool used as wellhead unit in all kinds of cementing operation. Comparing to cement head with single plug, it owns longer cement-head body , and upper rubber plug and lower rubber plug can be put in at same time.

Structure Types:
1—According to the gearing thread, there are two kinds cement heads: drill pipe cement head and casing cement head. The former connects with the drilling sended at the well head, the latter connects with the casing.
2—According to the usage, there are two kinds: single plug cement head and twin plugs cement head.
CASING CEMENT HEAD

Specification	ID (mm)	Length of Plug Container(mm)	Working Pressure(MPa)	Manifold
5 1/2″	121	300	35	2″Union
7″	154	350	35	2″Union
7 5/8″	168	350	35	2″Union
9 5/8″	225	350	35	2″Union
10 3/4″	250	350	35	2″Union
13 3/8″	316	350	35	2″Union

Casing Cement Head With Double Plug

Type	ST35-140	ST35-178	ST35-140	ST35-140
Size	139.7(5 1/2″)	177.8(7″)	244.5(9 5/8″)	339.7(13 3/8″)
Max.working pressure	35Mpa	35Mpa	35Mpa	20Mpa
Casing coupling thread	5 1/2″ LTC/BTC	7″ LTC/BTC	9 5/8″ LTC/BTC	13 3/8″LTC/BTC
Manifold interface	2″ union	2″ union	2″ union	2″union
ID of plug container (mm)	125	160	225	320
Length of plug container (mm)	450	460	560	560
Overall length	1886	1972	1701	2210

The top drive ROTATING cement head can be directly connected to the top drive and rotate the tail pipe. It is designed with a bypass circulation passage.It can be circulated by the top drive when the drill rod rubber plug is installed.

Characteristics and features

1. It can be directly connected to the top drive and rotate the tail pipe;
2. The design has a bypass circulation channel, which can still be circulated through the top drive when the drill pipe rubber plug is installed;
3. High-load bearing design to ensure safe rotation during string movement and cementing process;
4. It is reliable in sealing and can withstand high pressure.
