Product details

Suitable for small spare parts or small products with low output. Can be used in medical treatment, confidential processing, 3D printing dentures, precious metal gold and silver jewelry polishing，Deburring polish, deburring treatment, for stainless steel polishing,Copper polishing, aluminum alloy polishing, zinc alloy, replacement of inverter power can also be done, titanium alloy, gold and silver (in addition to the power supply to use inverter, polishing equipment configuration is also different).

Plasma polishing machine specific parameters

● The main body of the inner groove

◆ Material：3mm thick 316L stainless steel plate double-sided welding molding.

◆ Size： L 620mm W 420mm H 600mm

◆Insulation treatment： with 20mm rear paneled wood to insulate the inner groove and outer frame effectively to prevent safety accidents.

● Main body of the frame:

◆ Material： 50mm X 50mm X 2.0mm 304 stainless steel pass Welding molding.

◆ Overall dimension： L 1200mm W1080mm H 1680mm

◆ Operation panel ：2mm thick 304 stainless steel plate bent welding

◆ Lifting door： 40mm X 40mm X 1.0mm 304 stainless steel square welded into the outer frame, and then use 1.2 post 304 stainless steel plate bent and welded on the outside.

◆ door plate ：0.8mm thick 304 stainless steel plate bending molding

● Transmission mode

◆ Door drive

It is fixed to the right and left of the lifting door with a direct 30 linear guide rail, and is fixed to the lifting door with a 30MULL linear slider with a linear guide rail and a 304 stainless steel chain. (Stepper motor for desktop)

◆ Hanger drive

With a direct 30 linear guide rail fixed to the lifting frame around, with a 30MUL linear slider fixed to the lifting slide frame and linear guide rail, coupled with 304 stainless steel chain with a frequency converter to drive the deceleration motor to do the lifting action.

▼ Transmission mode: AC220V inverter drives the gear motor, gear motor

The drive chain drives the linear slider to open and close the door and lift the hanger

Move.

▼ Rack travel: 500mm

● Power supply： (three-phase full bridge rectifier or three-phase inverter rectifier)

◆ Three-phase full bridge rectifier power supply (suitable for materials other than gold, silver and titanium)

◆ Three-phase full bridge rectifier

▼ Working parameters

Input three-phase： AC 380V±5%

Frequency: 50HZ

Output power： 30kw

Voltage ：unadjustable (with the influence of external network)

Current ：max 100A

Cooling method: air cooling

◆ Three-phase inverter power supply (suitable for gold, silver, titanium)

▼ Working parameters

Input three-phase AC 380V±5%

Frequency: 50HZ

Output power 30kw

Voltage 0-400V adjustable constant voltage

Current max 100A

Cooling method Wind cooling

● Temperature control: 316 seamless stainless steel heating tube is used for heating, temperature sensor and AD temperature module are used to read the temperature into PLC, and then the temperature is controlled by PLC and contactor.

●Water level control: The float ball and micro switch are used, the micro switch signal is read into PLC, and the water refill solenoid valve is controlled by PLC operation.

●Air supply: the external compressed air is connected, and the compressed air is controlled through the throttle valve of the operation panel into the bottom of the inner tank to stir the tank liquid.

● Automatic turn over: 180° turn over with rotary telescopic cylinder inserted into hanger tenon (optional)

● Automatic clamping: The use of special cylinders through the transmission rod to achieve automatic clamping (optional device).

● Electrical and control

◆ The system control module is controlled by Xinjie PLC module.

◆ The use of Willon 7-inch color touch screen (desktop 5-inch control one

Body machine).

◆ Pure manual operation, full process automatic operation or partial manual operation

Do.

◆ Control cabinet distribution: Separate the control cabinet and DC power cabinet and place them separately (desktop machine as one).

● Venue layout

◆ Actual layout site size: L5000mm× W5000mm×H 2800mm (including the position of the sink, and the position of the upper and lower hanging table, excluding the position of the distillation drying tank and the mixing tower); The desktop machine is placed on the desktop.

◆ The height of the factory is not less than 2800mm.

● Surrounding requirements:

◆ Ensure that the compressed air pressure is more than 6kg/cm2.

◆ Tap water flow > 2t/hr pressure > 3kg/cm2.

◆ Power supply power supply wiring mode is three-phase and five-wire, voltage requirement 380V voltage fluctuation should not be high At ±5%.

● Power distribution:

◆ The cable adopts 3+2 16 square

◆ The total control switch adopts 100A

(If you need to configure the distillation drying tank, you can choose the cable line 3+2 25 square 200A total system switch)

◆ Exhaust pipe: need to be equipped with 160PP diameter exhaust pipe and PP exhaust fan or stainless steel exhaust fan.
