The skeleton type container transport vehicle is a kind of container transport Semi-Trailer frame, and the other is flat plate type. The frame type car is welded by longitudinal beam, beam and front and back end beams. The longitudinal beam is welded into I-shape by submerged arc welding of 16Mn steel plate (the main size is 450, 500). The beam is pressed into groove by steel plate, and the front and rear end beams are welded rectangular sections. The middle part of the container locking device is provided with an integral long beam to improve the load capacity of the container locking device. The difference between the plate type and the skeleton type is that the flat plate adds a border and a patterned floor. The frame of the wood series container transport Semi-Trailer is all shot peening treatment, and the whole frame is assembled and welded on the positioning bench. The structure is reasonable, the strength is high, and the appearance is beautiful. The container compression device is installed on the frame, which can load two standard containers of 40 feet and 20 feet. The four container tightening devices at the front and back ends are fixed structures, and the middle container tightening devices are storable structures. When loading containers, the intermediate container lock device can be lowered below the level of the arrival platform if necessary. Selection of mechanical bearing device, mainly Baohua 12T, 20T; Fuhua 13T; JOST; The same type. Its function is to support the ground and bear the front load of the Semi-Trailer when the traction device and trailer are detached. There are two kinds of supporting devices, single acting and linkage, which are mainly composed of supporting disc, screw transmission mechanism, reducer box and control handle. There are single-axle suspension and two-axle suspension three-axle suspension three kinds of devices Semi-Trailer is equipped with two spare tire frames, respectively installed on the left and right sides of the trailer frame, and spare tire elevators are provided.
Model number: GFDH6+
Type: demi-mount
Loaded weight: 40000 (kg)
Overall vehicle dimensions: 13000*2500*1710 (mm)
Saddle load: 90t
Saddle height: 1250mm
Number of tires: 12
Front overhang radius: 2850 (mm)
Payload: 40t
Wheelbase: 4500+1850+1850 (mm)
Maximum speed: 90 (km/h)
