Loren Multiple Channel Jet Areator （HS Code:8421299090）
Definition of Loren Butterfly Jet
It Is An Idea Device for Both Aeration and Oxygen Boosting to realize function of Mixing and Conditioning.which fit for Two Stage Mixing, DAF Air Injection, Water Pool Oxgen Boosting, Activated Sludge Pool , MBR, SBR, CASS Pools etc .
It is mainly composed of Outer and Inner Chambers, Mixed Chamber, outer and inner spraying nozzles , Air Intake and Liquid Inlet . itself doesn’t include any driving part, during working, need configure matching Injected circulated pump or blowers .
Performance Parameter of this Vortex Aerator
-Working Air Volume: 120-1200 m3/h Per Set
-Circulated Water Volume: 75-500 m3/h Per Set
-Oxygen Utilization Ratio:20-28.2%
-Oxygen Charging Capacity: 76.5-89.6 kg O2/H . Per Set
-Power Efficiency: 4.17-5.36 kg O2/KW.H
-Service Area
A. High Ammonia Nitrogen Industrial Wastewater:50-150 M2
B. City Sewage: 100-250 M2
Feature of Our Excellent Jet Areatror
-Working Water Depth Double Times than Ordinary Aerator (5-13m)
-Long Time Runn Without Blocking
-No Sealing Problem
-Higher DO Charging , Mixing and Thrust Flow Efficiency ,
-Max. Air Throught Volume:580m.h
-Large Sevice Area
-20-50% Higher Energy Saving For Its Power System
-When Feeding Air with both Oxygen and Mixing Function, Stop Air with Mixing Function
-Have 20% Fluctuation of Air and Oxgen Regulation Range which fit for VF control the Aerator System
-Easy Flange Mounting and Operation
-Flexible for Both Continuous and Sequency Aeration System
-Can Largely Improve Current System Capacity and Efficiency (upgrading)
-Compact Structure
-Long Working Life
Model Selection and Parameterof Butterfly Aerator
|
Model |
LBA-50 |
LBA-60 |
LBA-80 |
LBA-100 |
|
Outer Dimension (DN*H) mm |
500*400 |
600*500 |
1000*650 |
1400*700 |
|
Inner Sprayer DN(mm) |
12 |
14 |
40 |
50 |
|
Outer Sprayer DN(mm) |
25 |
30 |
80 |
80 |
|
Spray Nozzle NO.(pcs) |
6-10 |
8-10 |
12 |
12 |
|
Single Nozzle Liquid Volume (M3/h) |
6-14.5 |
12-24 |
15-30 |
30-60 |
|
Single Nozzle Air Volume (M3/h) |
15-48 |
18-54 |
26-78 |
48-150 |
|
Air/Liquid Joint DN (mm) |
80/100 |
100/150 |
150/200 |
200/300 |
|
Service Area |
≥50 |
≥60 |
≥80 |
≥100 |
Applicant of loren Butterfly Jet Aerator
-Garbage Leachate
-Kitchen Wastewater
-Petrochemical
-Dyeing and Printing
-Coal Chemistry
-Paper mill
-Starching Industry
-Achohol Waste Water
-Food Processing Waste Water
-Other Waste Water site
-Old Aeration Pool Upgrading
