Product details

API 6A wellhead equipment tubing head and tubing spool

Tubing head is a body with two flange that can supports the tubing string on a oilwell, seals off the pressure between the casing and tubing annulus, and connect with tubing adapter on the top.

Tubing Head & tubing spool are a straight bore bowl with 45° landing shoulder design which avoids damage to sealing areas by drilling tools, and provides wedging of the tubing hangers, bowl protectors and test plugs.

The secondary seal for the last casing pipe can be an integrated "o" seal type or the plastic injection type, but also accepts reducer bushings "4-O" and "PE" .

Tubing Head14 Jpg

The upper flange is supplied with lockdown screws for pack-off tubing hanger retention. The lower flange includes a grease fitting and orifice for testing of the secondary seal.

▲ spool and adapter can be designed according to customer's all kinds of models and sizes to meet the requirements in work site. there are three kinds of connecting models for bop.

▲connection and outlets. including flanged studded and clamped-in style.gasket groove is line welded by stainless steel according to API Spec 6A . so as to prolong the using period and decrease the maintaining cost.

Tubing Head 3 Tubing Head18 Png

Specifications and parameters

Product Name	Tubing Head
Working Pressure	2000 ~10000psi
Nominal Bore	7-1/16 ~13-5/8
Working Medium	oil,natural gas,mud and gas containing H2S,CO2
Working Temperature	-46°C~121°C(Class LU)
Material Class	AA,BB,CC,DD,EE,FF,HH
Specification level	PSL1-4

Packaging Details
1. Normal packing: plywood case, wooden box or pallet
2. Suitable for ocean shipping and air shipping.
3. Max. weight for each package: 1500 Kg
4. Standard packing dimension: 1200 * 1100 * 1000 mm
5. Special packing requirements should be known in advance.
6. Custom packing is available.

The tubing head is a device component that connects the uppermost casing head to the oil (gas) christmas tree to suspend the annular space between the oil pipe and the sealing oil pipe and the casing. The tubing head is located above the tubing head and includes the tubing tee and the tubing suspension. Its function is to suspend the oil pipe, downhole tool and sealing oil sleeve annular space in the well.
