YESWITCH X7 IP67 Illumination Rocker Switch

A safe and reliable high current rocker switch - X7 series. It has a high current of 25A, which can meet the needs of various electrical appliances.

First of all, the X7 rocker switches have the dustproof and waterproof function of IP67 level, which can effectively prevent water droplets, dust and other debris from entering the inside of the switch to ensure the normal use and safety performance of the switch. Secondly, the IP67 rocker switch also has the momentary and self-lock function,which means that the switch can be automatically reset to the initial position, avoiding the cumbersome and unsafe factors of manual operation. In addition, the X7 high-current waterproof rocker switch can also select single pole or double pole functions according to needs, such as ON-OFF, ON-ON,ON-OFF-ON,( 63429663,ON)-OFF-ON, etc., to facilitate users to carry out different control needs.

Most importantly, the X7 high-current rocker switch also has an led indicator, which allows users to clearly know the working status of the appliance, avoiding safety hazards caused by uncertainty. These advantages make the X7 rocker switch widely used in boats,construction equipment,agricultural equipment,recreational vehicle,landscaping equipment and industrial equipment.It’s a very practical switch products.

Feature

16(8)A 125/250V~T55, T125/55 (cURus)

20(8)A 125/250V~T55, T125/55 (cURus)

25(8)A 125/250V~T55 (cURus)

16A 6~48VDC T55, 40T125/55 (cURus)

20A 6~36VDC T55, 40T125/55 (cURus)

Dielectric strength : 1,500VAC for 1 min.

Insulation resistance : 100M ohm MIN. at 500VDC

Initial contact resistance : 20m ohm MAX

Electrical life : 10,000 cycles

ON-OFF-ON, ON-ON, ON-OFF or other momentary functions available

Two LEDs for custom color selection

quick connecting terminals

Plastic housing and actuator

Suitable for outdoor application

Sealed to protection level IP67 ( passing MIRDC's TAF laboratory test )

How to order

Panel cutout
X7..

Item
