ZHP multi cylinder cone crusher
ZHP multi-cylinder cone crusher is an efficient and reliable crushing equipment, which is widely used in mining, metallurgy, building materials, cement and other industries, especially in the processing of various ores and rocks with medium and above hardness.
ZHP multi-cylinder cone crusher adopts advanced design concept and manufacturing technology, with high production capacity, small particle size, stable work, reliable performance and so on. Its core components include motor, drive shaft, gear, eccentric sleeve, fixed cone and moving cone, etc., through the principle of laminating crushing to achieve the crushing of materials. At work, the material enters the crushing chamber from the feed port of the crusher, is subjected to the action of the high-speed rotating cylinder and the impact force, and after multiple impacts, collisions and friction, the material is finally broken into the required particle size and discharged from the discharge port.
The multi-cylinder design is a highlight of the crusher, through the distribution of multiple hydraulic cylinders around the frame, to achieve the integration of the upper and lower frames during the crushing process, while having the back-off protection of unbreakable objects and the cavity cleaning function of sudden stop. This design not only improves the stability and reliability of the crusher, but also reduces the maintenance cost and extends the service life of the equipment.
In addition, ZHP multi-cylinder cone crusher also adopts the design of large eccentricity and high revolution spindle, which can achieve a large crushing ratio and has the advantage of a high proportion of disposable products. At the same time, the crusher is also equipped with an intelligent control system, which can adjust parameters according to different crushing needs, improve crushing efficiency and reduce energy consumption.
In short, ZHP multi-cylinder cone crusher is a crushing equipment with excellent performance, easy operation and easy maintenance, which can meet the needs of various complex crushing operations and provide strong support for the production and development of enterprises.
Welcome to our details page, the range of products includes construction machinery such as medium and large excavators, mini excavators, and pile drivers, mining equipment like crushers, and energy equipment comprising generator sets. Welcome detailed consultation
| Model | ZHP100 | ZHP200 | ZHP300 | ZHP400 | ZHP500 | ZHP800 |
| Technical specifications | ||||||
| Head diameter | 735 mm | 940 mm | 1120 mm | 1320 mm | 1520 mm | 1780 mm |
| Power | 90 kW | 132-160kW | 220-250 kW | 315 kW | 355-400kW | 600 kW |
| Crusher weight | 6470 kg | 12160 kg | 18100 kg | 25600 kg | 37000 kg | 64100 kg |
| Feed opening | ||||||
| Maximum | 150 mm | 185 mm | 241 mm | 304 mm | 351 mm | 375 mm |
| Capacity TPH | ||||||
| Closed side setting | ||||||
| 6 mm | 45-55 | |||||
| 8 mm | 50-60 | |||||
| 10 mm | 55-70 | 90-120 | 115-140 | 140-175 | 175-220 | 260-335 |
| 13 mm | 60-80 | 120-150 | 150-185 | 185-230 | 230-290 | 325-425 |
| 16 mm | 70-90 | 140-180 | 180-220 | 225-280 | 280-350 | 385-500 |
| 19 mm | 75-95 | 150-190 | 200-240 | 255-320 | 320-400 | 435-545 |
| 22 mm | 80-100 | 160-200 | 220-260 | 275-345 | 345-430 | 470-600 |
| 25 mm | 85-110 | 170-220 | 230-280 | 295-370 | 365-455 | 495-730 |
| 32 mm | 100-140 | 190-235 | 250-320 | 325-430 | 405-535 | 545-800 |
| 38 mm | 210-250 | 300-380 | 360-490 | 445-605 | 600-950 | |
| 45 mm | 350-440 | 410-560 | 510-700 | 690-1050 | ||
| 51 mm | 465-630 | 580-790 | 785-1200 | |||
