Lithium Battry Slurry Filter
Working principle
The raw liquid enters into the filter through the inlet. During the filtration process, the impurity accumulated on the SS wedge wire filter element, and the inner impurity would be gradually accumulated.
1. Automatic cleaning: When filtration working time reaches the set point, the electronic control system signal will work. The reducer begins to work; the reducer drives the metal scraper to remove the particles on the filter element external surface. When cleaning time reaches the set point, the drain valve is opened to blow down.
2. Manual cleaning: The reduder drives scrapers to remove the particles on the filter element external surface continuously. When the time reaches the set point, the drain valve opens and starts to blow down.
Related other Liquid Filtration, Automatic Filter,Scraper Self-cleaning Filter,Bag Filter,Basket Filter, Multi Media Filter,Quartz Sand Filter,Caldle Filter,Ultra Precision Filter,Cartridge Filter and Parts.
Specification of Lithium Battry Slurry Filter
Model: HT018
Filtration surface area: 0.18㎡
Filter element: Wedge wire screen (v-slot screen)
Filtration rate: 0.15mm (minimum 20microns).
Housing material: SS304/ SS316L/ 2205/ 2507…
Filter element material: SS304/ SS316L/ 2205/ 2507…
Inlet: 1.5" quick coupling connected
Outlet: 1.5" quick coupling connected
Drain outlet: 1" 1.5" quick coupling connected
Motor: 24V 120V
Air hole: 3/4"
Housing material: SS304
Filter element material: SS304
Scraper material: PTFE
Blowdown valve: manul valve
Filter surface treatment: Electric polish/ Sand-blasting/ Painting
Features of Lithium Battry Slurry Filter
1. Intelligent control system
The system operates 24/7, continuously filtering, cleaning, and draining water, and can switch between manual and automatic modes to meet the different filtration needs of customers.
2. Scraper driving device
The equipment adopts a well-known domestic brand reducer to drive the internal high-wear-resistant stainless steel scraper cleaning system of the equipment, which can adapt to the 24-hour continuous working environment without frequent replacement of consumables.
3. Core filter element
This equipment uses a self-developed wedge-shaped wire filter element, using imported wedge-shaped wire. The filtration precision is 20-3500 microns, and it can handle liquids with viscosity up to 800,000 centipoise.
4. Cylinder quick opening structure
The top and bottom of the equipment cylinder are designed with two quick-release lifting rings to facilitate cleaning of internal components. The operation is simple and efficient, improving operating efficiency and reducing maintenance costs.
Applicable industry Lithium Battry Slurry Filter
1. Lithium battry slurry
2. Food & Beverage,Fine Chemical,Petrochemical,Pharmaceutical,Cosmetic,Mineral,Pulp&Paper,Waste water Treatment
