DX51D Galvanized Steel Coils

DX51D Galvanized Steel Coil is one kind of steel coil with grade under BS EN 10346:2015 standard. Houming also provide galvanized steel pipe, stainless steel coil etc.

With EN 10346, there are

DX51D: bending and profiling quality
DX52D: drawing quality
DX53D: deep drawing quality
DX54D: special deep drawing quality
DX55D: special deep drawing quality (only +AS)
DX56D: extra deep drawing quality
DX57D: super deep drawing quality

DX51D has many coating:

Z means zinc coating
ZF means zinc-iron coating
ZA means zinc-aluminium coating
ZM means zinc-magnesium coating
AM means aluminium-zinc coating
AS means aluminium-silicon coating

Product advantange:

good durability
Lifespan is as long as 30 years
Excellent waterproof

Product application:
DX51D is manily used in uncoiler, welder, annealing furnace industry, cooling tower, water tank industry etc.

Chemical content:

GRADE	C	Si	Mn	P	S	Ti
DX51D	0.18	0.50	1.20	0.12	0.045	0.30
DX52D	0.12	0.50	0.60	0.10	0.045	0.30
DX53D	0.12	0.50	0.60	0.10	0.045	0.30
DX54D	0.12	0.50	0.60	0.10	0.045	0.30
DX55D	0.12	0.50	0.60	0.10	0.045	0.30
DX56D	0.12	0.50	0.60	0.10	0.045	0.30
DX57D	0.12	0.50	0.60	0.10	0.045	0.30

Mechanical properties:

GRADE	Coating code	Yield Strength /MPa	Tensile Strength /MPa	Elongation A80 /%
DX51D	Z/ZF/ZA/AZ/AS	/	270-500	22
DX52D	Z/ZF/ZA/AZ/AS	140-300	270-420	26
DX53D	Z/ZF/ZA/AZ/AS	140-260	270-380	30
DX54D	Z/ZA	120-220	260-350	36
DX54D	ZF	120-220	260-350	34
DX54D	AZ	120-220	260-350	36
DX54D	AS	120-220	260-350	34
DX55D	AS	140-240	270-370	30
DX56D	Z/ZF	120-180	260-350	39
DX56D	ZF	120-180	260-350	37
DX56D	AS	120-180	260-350	39
DX57D	Z/ZF	120-170	260-350	41
DX57D	ZF	120-170	260-350	39
DX57D	AS	120-170	260-350	41
