Product details
JIS G3106 hot rolled steel plate
G3106 hot rolled steel plate is one kind of steel plate for welded structure, it is belongs to the Japanese Industrial Standard (JIS).

G3106 hot rolled steel coil or plate has below garde (S means structure, M means  Mechanical, number means the tensile strength ):
  • SM400A
  • SM400B
  • SM400C
  • SM490A
  • SM490B
  • SM490C
  • SM490YA
  • SM490YB
  • SM520B
  • SM520C
  • SM570

Product application:
JIS G3106 are mainly used for welded structures such as bridges, ships, rolling stock, petroleum storage tanks and containers and highly weldable hot extruded sections.

Chemical content:

Grade Thickness C Si Mn P S
SM400A 50 mm max 0.23 max / ≥2.5× C 0.035 0.035
SM400A 50-200 mm 0.25 max / ≥2.5× C 0.035 0.035
SM400B 50 mm max 0.20 max 0.35 max 0.60-1.50 0.035 0.035
SM400B 50-200 mm 0.22 max 0.35 max 0.60-1.50 0.035 0.035
SM400C 100 mm max 0.18 max 0.35 max 0.60-1.50 0.035 0.035
SM490A 50 mm max 0.20 max 0.55 max 1.65 max 0.035 0.035
SM490A 50-200 mm 0.22 max 0.55 max 1.65 max 0.035 0.035
SM490B 50 mm max 0.18 max 0.55 max 1.65 max 0.035 0.035
SM490B 50-200 mm 0.20 max 0.55 max 1.65 max 0.035 0.035
SM490C 100 mm max 0.18 max 0.55 max 1.65 max 0.035 0.035
SM490YA 100 mm max 0.20 max 0.55 max 1.65 max 0.035 0.035
SM520B 100 mm max 0.20 max 0.55 max 1.65 max 0.035 0.035
SM520C 100 mm max 0.20 max 0.55 max 1.65 max 0.035 0.035
SM570 100 mm max 0.18 max 0.55 max 1.70 max 0.035 0.035

Mechanial properties:

Yield strength (Mpa) T: 16mm max T: 16-40mm T: 40-75mm T: 75-100 T: 100-160 T:160-200mm
SM400A SM400B 245 min 235 min 215 min 215 min 205 min 195 min
SM400C 245 min 235 min 215 min 215 min / /
SM490A SM490B  325 min 315 min 295 min 295 min 285 min 275 min
SM490C 325 min 315min 295 min 295 min / /
SM490YA SM490YB 365 min 355 min 335 min 325 min / /
SM520B SM520C 365 min 355 min 335 min 325 min / /
SM570 460 min 450 min 430 min 420 min / /
