3.2v 105ah Lifepo4 Forklift Battery Project
|
Description
|
Size
|
|
L
|
Width
|
130.3±0.3mm
|
|
W
|
Thickness
|
36.7±0.5mm
|
|
H
|
Height（total height）
|
200.5±0.5mm
|
|
H1
|
Height(body height)
|
195.5±0.5mm
|
|
D
|
The center distance of the pole column
|
67.0±1.0mm
|
|
S/N
|
Item
|
Content
|
|
1
|
Nominal capacity
|
105Ah
|
|
2
|
Model Number
|
ZT32105A
|
|
3
|
Dimension
|
130*37*200 MM
|
|
4
|
Rated voltage
|
3.2V
|
|
5
|
Rated Capacity
|
105Ah
|
|
6
|
AC Impedance resistance (1KHz)
|
≤0.5mΩ
|
|
7
|
Standard charge/discharge
|
Current of charge/discharge : 0.5C/0.5C
Cut-off voltage of charge/discharge : 3.65V/2.5V
|
|
8
|
Max current of charge/discharge
|
Constant charge/discharge : 1C/1C
Pulse charge/discharge : 1C/3C
|
|
9
|
Recommend SOC window
|
10%~90%
|
|
10
|
Cycle life at 25℃
|
≥3500 cycle @1C/1C
|
|
11
|
Weight
|
1980±100g
|
|
12
|
Storage humidity
|
＜95%
|
|
13
|
Charge temperature
|
0℃ ～55℃
|
|
14
|
Discharge temperature
|
-20℃ ～55℃
|
|
15
|
certificate
|
MSDS,ISO9001,CE,UN38.3,ROSH
|
