PVC-U Inner Wall Spiral Silencing Pipe

6 month ago

28 0

Zhengzhou guan hao yong International Trade Co.,

 7 month year

Product details

Inner Wall Spiral Silencing PVC Pipe is a pipe material with special design and function, mainly used for drainage system to reduce the noise generated by water flow. It is a special drainage system that can realize a PVC riser with drainage, ventilation and sound insulation and noise reduction triple functions. The system solves the problems of large noise reduction, small drainage capacity and large installation workload of the existing building pvc pipe. According to the principle of "sound insulation quality law", with PVC resin as the main raw material, adding special suction / sound insulation function materials and processing additives, developed extrusion pipe, according to the study of the drainage system, independently developed cyclone drainage series of pvc pipe fitting, and obtain the large diameter pipe, cyclone drainage fluid, spiral vertebra.

Product features:
1. Good drainage and ventilation function:The spiral design forms a smooth air column on the inner wall of the riser, improving ventilation capacity, reducing pressure inside the pipe, and increasing drainage capacity.
2. Noise reduction:The inner wall spiral silencing pvc water pipe adopts a spiral design, which can effectively reduce the collision between water flow and the pipe wall, thereby reducing the noise generated during the drainage process. According to experimental data, it can reduce noise by 8-10 decibels compared to standard solid wall tubes.
3. Improving the water flow state: The spiral lines on the inner wall of the spiral pipe make the water flow adhere to the wall, reduce the water flow velocity, reduce the water resistance coefficient, maintain the central gas core in the riser to connect up and down, and stabilize the pressure fluctuations inside the pvc pipe.
4. Strengthening effect: The triangular spiral main reinforcement on the inner wall of the pipe has a significant strengthening effect, which can effectively reduce the phenomenon of pipeline rupture caused by external force impact.
Application area:
1. high-rise residential steel building, hotels, apartments and other mobile home buildings on 10 floors and above 10 floors;
2. Multi-storey residential building, hotel, apartment and other buildings with higher building standards;
3. Under the condition of considering the chemical resistance and heat resistance of materials, it can also be used in industrial drainage system;

4. PVC-U Inner Wall Spiral Silencing Pipe system can also be used for sewage and wastewater confluence system or sewage and wastewater diversion system; the laying method can be the same layer drainage or different layer drainage.

Pvc U Silencing Drainage Pipe
