FS-13 400-1000nm Precision Line-Scan Hyperspectral Camera for Laboratory Settings with Consistent Light Source Stand

Visible spectrum/NIR:

Spectral range: 400-1000nm, with a wavelength resolution better than 2.5nm and up to 1200 spectral channels.
Acquisition speed: up to 128 FPS across the entire spectrum, reaching up to 3300Hz with band selection (supports multi-region band selection).
Commonly used for detecting surface color and texture in printing, textiles, and other industrial products. Single pixel color measurement repeatability achieves dE* AB < 0.1.

SW-NIR:

Spectral range: 900-1700nm, with a wavelength resolution better than 8nm and up to 254 spectral channels.
Acquisition speed: up to 200 FPS across the entire spectrum.
Extensively used in fields such as composition identification, material identification, machine vision, and quality assessment of agricultural products.

FS-13 400-1000nm Precision Line-Scan Hyperspectral Camera for Laboratory Settings with Consistent Light Source Stand

Serial number	Index	Parameter
1	Spectral range	400-1000nm
2	Spectral band	1200
3	Spectral FWHM	2.5nm
4	Slit width	25um
5	Transmission efficiency	>60%
6	Stray light	<0.5%
7	Spatial pixel number	1920
8	Pixel size	5.86um
9	Imaging speed	Full band 128Hz 3300Hz can be achieved after ROI
10	Detector	CMOS
11	SNR(Peak)	600/1
12	Camera output	USB3.0
13	Camera interface	C-Mount
14	Accessories	USB3.0 transmission line
15	ROI	Single area
16	Dimension	Length x width x height: 22.8 cmx7cmx8. 6 cm
17	Weight	1250g
18	Power dissipation	5 w

Serial number	Content	Serial number	Content
1	Hyperspectral Camera *1	7	Power cord *1
2	White calibration board *1	8	charger*1
3	25mm lens *1	9	Warranty card*1
4	Test Bench *1	10	User manual*1
5	USB flash drive*1
6	USB 3.0 data cable*1
