160Watts High power Manpack drone or mobile phone UAV Drone Jamming Module Jammer for cellular phones, GSM 3G 4GLTE/WIMAX 5G Wi-Fi GPS UHF VHF Signals which are currently presented on the market. Also is middle RF power UAV Drone Jammer model with 6 high gains antennas which bring us a strong jamming ability. Build-in battery can works 60 minutes, And it can defend 100% drones UAVs, like Phantom 4, Phantom 3 Professional, advanced, standard series, inspire series up to 500meters
Advantage
High power backpack style, Army use to jam the RC bomb or drone
Output power total 160w, You can choose high gain 5-10 dbi OMNI or Panel directional Jammer Antenna, shielding 200-2000m,
Each unit can jam up to 6 frequency bands, Modular design,Easy maintenance, repair and upgrade
100% safe VSWR over protection for each modular
Big aluminum alloy shell and 4 pieces cooling fans, not-stop to work
Build-in AC power DC27V and Battery 27V20Ah continue working 60 minutes,
Option: Line Control turn ON/OFF each band and with Battery Power and charger stative display via LCD screen
OEM Customized Service
20MHz-6GHz wide frequencies range.
Application
It can be applied at meeting rooms, conference rooms, museums, galleries, theatres, concert halls, churches, temples, restaurants, classrooms, training centers, factories, banks, trains, bus and more Places that require silence, confidentiality and information security For some locations of special purpose such as hospitals, gas stations and more, please do field test first to make sure no interference happened to the normal operation of their equipment and instrument
|
Key specifications：MP6-D |
|||||
|
Channel |
Output Port |
Frequency range |
Average out-putting power(±1dbm) |
||
|
1 |
RC2.4G |
2400-2500MHz |
40W |
||
|
2 |
RC5.8G |
5700-5900MHz |
30W |
||
|
3 |
GPSL1 |
1560-1610MHz |
20W |
||
|
4 |
GPSL2L5 |
1170-1280MHz |
20W |
||
|
5 |
868/915 |
840-940MHZ |
20W |
||
|
6 |
RC5.2G |
5125-5350MHz |
30W |
||
|
Option |
RC400 |
430-440MHz |
10W |
||
|
|
RC1400 |
1400-1500MHz |
10W |
||
|
Power supply: AC adapter 50 to 60Hz, (AC110 or 240V-DC27V) Battery 27V20Ah working 1.0hours) |
|||||
|
Dimension: (length,width, height ) 510 x 370 x 240 mm(Not include antenna) |
|||||
|
Package Size: 550 x450 x 300mm |
|||||
|
Output power total 160w, with omni-directional antennas anti drone 200-1000m, with directional antennas anti drone up to 2000m, Still depends on the strength signal in given area. |
|||||
|
Warranty: one year from delivery date |
|||||
|
|||||
