X89 I5-1135G7U

X89 I5-1135G7U

2 month ago

5 0

Shenzhen Innovative Cloud Computer Co., Ltd.

 3 year year

Product details

This X89 model is a fanless embedded Industrial Mini PC, equipped with lntel Core i5-1135G7/6300U, i7-1165G7/1185G7 processor. Dual LAN, 6* RS232 COM port, etc. rich interfaces of this model fit many working environments.

A Mini Computer host is a powerful portable computer with excellent processing power and efficient cooling system. It is equipped with two high-performance hard disks and DDR4/DDR3L large capacity memory, making it easy to handle multitasking operations and the operation of large software.

As a fanless Mini PC, it supports multiple operating systems and is equipped with rich applications and functions to meet various usage needs.

Product Details

CPU: Intel Core i5-1135G7/6300U/4200U, i7-1165G7/1185G7

Memory: Intel Core i5-1135G7/6300U, i7-1165G7/1185G7: 2*DDR4 SODIMM, Max up to 32GB; Intel Core i5-4200U: 2*DDR3L SODIMM, Max up to 16GB

Hard disk: 1*MSATA SSD, 1*SATA SSD/HDD

LAN: 2*Intel-I225V2.5G LAN, support wake on LAN and PXE boot

I/O Port: 4*USB3.0, 4*USB2.0 (Intel Core i5-4200U only has 3*USB2.0 and 4*USB3.0), 1*VGA , 1*HDMI1.4, 6*DB9RS232 COM (COM1-COM2 in BIOS can support RS232/422/485), 1*Power button, 1*SPK, 1*MIC, 1*DC

OS: Windows10/11, Linux

Expansion Slot: 1*MINIPCIE slot support Wifi/Bluetooth, 1*MINIPCIE slot support 3G/4G/Wifi module, 8*GPIO 4-way input/output (Note: Motherboard pins, can be customized for expansion)

Suitable Temperature: Storage Temp:-30℃ to +70℃, Operating Temp:-20℃ to +65℃, Relative Humidity 5%~95% (non-condensing)

Dimensions: 240*150*69mm, Weight: about 1.75kg

Power: DC12V, default 12V6A

This fanless embedded Industrial Mini PC, equipped with lntel Core i5-1135G7/6300U, i7-1165G7/1185G7 processor, two high-performance hard disks and 2*DDR4 (Intel Core i5-4200U processor has 2*DDR3L) large capacity memory, making it easy to handle multitasking operations and the operation of large software.

The finned structure design, which conducts heat through the all-aluminum alloy body, can better reduce the noise and the influence of environmental dust accumulation and make the machine run more stably.

Due to the harsh industrial environment site, so the dual-network 6 serial port industrial control host has a stronger adaptability to cope with high temperature and humidity and other environmental changes, with dust-proof, corrosion-resistant, high and low temperature resistance (-20°C to +65°C) and other capabilities.

Equipped with diverse interfaces to meet various needs, this mini PC features ultra-high performance, low power consumption and more. It also supports dual-screen synchronized asynchronous display, which improves operational efficiency.

*Intel Core i5-4200U only has 3*USB2.0 and 4*USB3.0

The Industrial computer is widely used in industrial automation, intelligent manufacturing, ATMs, automotive systems and other fields, bringing great help to our lives.
