Product Name |
cheap price wholesale transducer piezo buzzer |
|
Product picture |
 |
Characteristics
|
No. |
Item |
Specifications |
|
1 |
Rated Voltage |
3.0 Vo-p |
|
2 |
Operating Voltage |
2.0~4.0 Vo-p |
|
3 |
Rated Current |
Max.100mA ,at 4000Hz 50% duty Square Wave 3.0Vo-p |
|
4 |
Sound Output at 10cm |
Min. 75dB, at 4000Hz 50% duty Square Wave 3.0Vo-p |
|
5 |
Coil Resistance |
12±3Ω |
|
6 |
Resonant Frequency |
4000Hz |
|
7 |
Operating Temperature |
-30℃~+70℃ |
|
8 |
Store Temperature |
-40℃~+85℃ |
|
9 |
Net Weight |
Approx 0.1g |
|
10 |
RoHS |
Yes |
Drawing
If you are interested in the product, contact 2bvideo.com for more information for more information
