Heat-Resistant 0.025 mm Metallized Polyimide Film PI Film
Heat-Resistant Metallized Polyimide Film PI Film is also named Kapton Polyimide Film (KAPTON FILMS). It is made of Amber color Polyimide film with aluminum coated . It have excellent insulation material. The density is 1.39-1.45, polyimide film has excellent resistance to high and low temperature, electrical insulation, adhesion, radiation resistance, resistance to medium, It can be used in the temperature range of -269℃ ~ 280℃ for a long time, can reach 400℃ in a short time.The vitreation temperatures were 280℃(Upilex R), 385℃(Kapton) and above 500℃ (Upilex S), respectively.The tensile strength is 200MPa at 20℃ and greater than 100MPa at 200℃.Especially suitable for flexible printed circuit board substrate and various kinds of high temperature electrical insulation materials.
Excellent properties:
1. High temperature resistant,
2.Resistance to radiation,
3.Resistance to chemical corrosion
4. Electric insulation performance
Technical Index:
It is available in thicknesses from 0.0003" (7.5 µm) up to 0.005" (125 µm).
And the avaiable color is Gold transparent , transparent , black ect
|
No. |
Test Item |
Unit |
Standard |
||||||
|
25μm |
30μm |
40μm |
50μm |
75μm |
100μm |
||||
|
1 |
Density |
g/cm3 |
1.400±0.020 |
||||||
|
2 |
Tensile Strength |
Vertical |
MPa |
≥135 |
|||||
|
Horizontal |
≥115 |
||||||||
|
3 |
Elongation ratio |
Vertical and Horizontal |
% |
≥35 |
|||||
|
4 |
Shrinkage |
% |
|
||||||
|
5 |
Frequency Electrical Intensity |
Average Value |
MV/m |
≥150 |
≥130 |
≥110 |
|||
|
Individual Value |
≥100 |
≥80 |
≥70 |
||||||
|
6 |
Surface Resistivity (200°C) |
Ω |
≥1.0X1013 |
||||||
|
7 |
Volume Resistivity (200°C) |
Ω·M |
≥1.0X1010 |
||||||
|
8 |
Relative Dielectric Constant 48-62Hz |
|
3.5±0.4 |
||||||
|
9 |
Dielectric Loss Factor 48-62Hz |
|
≤4.0X10-3 |
||||||
|
10 |
Long-term Heat-Resistance Temperature Index |
|
≤180 |
||||||
Product pictures:
Amber Color Polyimide film
Black Color Polyimide Film
Application:
Heat Resistance Polyimide film used in substrates for flexible printed circuits, transformer and capacitor insulation, sensors and bar code labels.
Kapton PI film is also used for wire and cable tapes, formed coil insulation, substrates for flexible printed circuits, motor slot liners, magnet wire insulation, transformer and capacitor insulation, magnetic and pressure-sensitive tapes
Contact:
Our company (Shijiazhuang DADAO Packaging Material CO.,Ltd) is establised in 2004. we have much experience in plastic film.
Our main products including :1.Metallized Film (VMPET,VMBOPP,VMPI ect ) 2.color PET film (PET Milky White Film , PET white film , PET black film ect )
3.3D Holographic Foil 4.PI FILM ect
These products are widely applied to the packaging and printing of the industries including electronical products, food, commodities, medicine, labels, gifts etc.If you need anything, please feel free to contact me.
