The medical hospital automatic door is a door that is generally installed in the operating room or the ICU ward for the medical staff to push in and out of the hospital bed. The medical automatic door has the function of inductive opening and safety anti-pinch. The medical staff only needs to extend the foot into the light control foot sensing box next to the entrance, and the door will automatically close. Door panel inside filled polyurethane foam with technology overall high-pressure, high-strength aluminum alloy frame, the automatic lifting large platform hydraulic pressing equipment.
Inner and outer doors of all kinds of factories especially fit for food factory ,cold storage frequent logistics , chemical industry. Designed for clean room enviromments such as hospital operating rooms, pharmaceutical production plants, precision equipment factories, food shop, laboratory access port.
--Main Features:
Security,heat preservation,wind resistance,sound insulation,durable.
--Application Scope:
Exterior & interior door of all kinds of factories and commercial buildings, especially in area with a high demand of safety.
After a period of time, the door will automatically close after the cart and medical staff have fully entered. If someone or a cart is next to the door leaf, the door will not close to provide a safe anti-pinch. In addition, the door frame of the medical automatic door is made of sealed profile, which has the characteristics of high air tightness; the light control foot sensing is adopted for the entrance and exit, so that the medical staff can open the door [without contact", which can effectively isolate the bacteria and personnel.
Technical Data:
| Door Leaf |
a> 1.0mm 304 stainless steel or galvanized steel with powder coating treatment b> Filled with high-density paper honeycomb,aluminium honeycomb or rock wool c> The thickness of door leaf is 50mm |
| Door Frame | 1.5mm galvanized steel or 304 stainless steel |
| Motor | Imported motor,Power Supply : AC110V / 220V 50HZ |
| Opening speed : 250 to 550 mm / s | |
| Hold opening time : 2-20 s | |
| Consumption < 150W | |
| Cover Box | Stainless steel or galvanized steel with powder coating treatment |
| Seal Structure |
a> Embedded seal groove design with all-around EPDM weather seal rubber between frame and leaf b> Thickness of EPDM seal rubber: 3mm c> Automatic seal rubber is installed at the bottom of the door leaf,which will automatically close the gap with ground floor when door is closed |
| Vision Window |
a> Special clean room glass is made of double layer tempered glass b> The glass and door fan are on the same plane to avoid dust retention and easy cleaning |
| Hardware | SUS 304 stainless steel |
| Working Temperature | -20 ºC to +50 ºC |
--What are the details of our automatic airtight hospital door?
| Power voltage | 220 V/ 50 Hz |
| Power consumption |
<150 W |
| Door weight |
<200 kg |
| Opening /Closing speed |
20-60 cm/sec |
| Closed way |
Auto/ induction |
|
Product performance |
Good insulation performance, strong sealing, low noise, anti-theft, wind resistance, beautiful |
|
Operating system: |
Manual, electric, fully automatic, semi-automatic |
|
The scope of application: |
For the exterior doors of high-end factory buildings. |
|
Safety performance |
The door has a fall arrest system, configurable airbag system, infrared security system. |
| Material |
High quality 304 stainless steel |
--The Graphical diagram of our hospital sliding door:
--The medical automatic door production method:
--Technical Data:
| Product Standard | Comply with CE standard |
| Service life | Service life : >10 years |
| Surface Treatment | Electrostatic powder coating, color is optional |
| Door Fan | a.Material: Ma'anshan or the same high quality brand of galvanized steel |
| b.The thickness of door fan is 50 mm | |
| c.The thickness of steel plate is 1.0 mm | |
| d.Internal filling : Honeycomb paper | |
| Door Frame | a.Material: Ma'anshan or the same high quality brand of galvanized steel |
| b.The thickness of door frame is 100 mm | |
| c.the thickness of steel plate is 1.5 mm | |
| Hardware | a.Stainless steel bearing butterfly hinge to ensure rotating flexible rotation |
| b.Stainless steel handle lock of Shanghai Xiandao as standard, or customer-tailor | |
| c.Window,door closer,escape push bar lock,step threshold,blinds is optional | |
| Sealing | All-round sealing |
| Reinforced Plate | a.Hinge, door closer and other hardware locations are equipped with reinforced plate |
| b.The thickness of reinforced plate is 3-5 mm |
