Brief introduction of bus combination grinding machine parameters
1 Device size length 3800 MM width 1550 MM height 2500MM
2 motor; Rough grinding 11KW Fine grinding 7.5KW Cutting slot 7.5KW Brush 1.1KW drive motor 1.5KW.
Grinding head bearing sleeve sand turning treatment, annealing treatment, internal and external circular grinding process, ensure its high precision!
Grinding head adjustment Manual worm adjustment, high precision optical deletion electronic ruler closed installation, digital display table display.
High frequency heat treatment of rectangular guide rail, sand turning of slide block, fine grinding of guide rail + oil guide groove are adjusted under the grinding head.
White steel fixed guide rail nodular cast iron 400 integral sand turning, track milling, left and right manual adjustable, with screw display.
7. The liner baffle is made of stainless steel, manual adjustment, plus screw display.
Each grinding head is equipped with a closed dust cover and an integral shell dust cover.
9 Turning mode Maltese cross mechanical transmission {no separate motor to reduce the degree of accident}
10 transmission mode roller chain, continuous release chain frequency conversion.
10 Operation mode Touch screen and PLC control.
11 Electrical Schneider [except frequency converter]
PLC is a well-known brand in Taiwan.
13 Maximum plant capacity 28 pieces/min {variable frequency adjustable}
The precision of the whole machine is less than 20 wire, and the weight is about 6T.
