Applicable to：
Rapier loom, air jet loom, water jet loom, shuttle loom, projectile loom with any reed width.
Weaving Products:
Label, tie, upholstery fabric, curtain fabric, shading fabric, sofa cloth, bedding cloth, towel, carpet, velvet, garment fabric, sari fabric, silk fabric, lining fabric etc.
SLX cam jacquard machine in strict material selection and production process perfect balance of moving parts, conjugate cam oil bath lubrication, all bearings permanent lubrication to ensure wear resistance, long service time, maintenance work will be reduced to a minimum, coaxial system driven by conjugate cam. Further strengthened drives and sturdy base make the machine to withstand higher loads. More characteristics include.
1. Sealed fuselage, optimized filtration and ventilation system can effectively prevent flying flowers into the system.
2. The optimized shuttle opening keeps good effect. The opening curve can be designed according to the need to ensure the best weft insertion, reduce the tension on warp yarn and breaks
3. The self-locking characteristic of the conjugate CAM can reduce the interference to the braking performance of the loom
4. The concentrated lubrication oil hole and grease hole are easy to reach and check.
5.The small pull rod composite bearing with special filling hole, to ensure the longer service time.
6.Shed height:55-120mm.
7.Max Speed:750rpm.
The chain-driven jacquard machine has been tested by the market for a long time, and we continuously optimize the process to provide customers with a better experience.
1. Sealed fuselage, optimized filtration and ventilation system can effectively prevent flying flowers into the system.
2. hi efficiency with the most concise shedding mechanism and crank direct drive pulling mechanism.the most concise shedding mechanism and the fewest parts offer easy maintenance and the cost is also much lowered.
3. high speed and low torque are more suitable for making large and heavy design fabrics.hollow type of core parts, with light inertia which is specialized for high speed and heavy pattern.
4. chain driving shedding system standard parts,with efficiency as high as 96%. the bearing capacity and life of self-lubricating chain is 5 times of common chain. With a good mechanical properly, the casting wallboard makes the vibration decreased, noise reduced and lifetime extended.
5. adopting elastic diaphragm which is free- maintainance,low inertia, high elasticity, high torque and no noise.
6. shed height:55-120
7. Max speed:850rpm
