Automatic Sausage Clipper
CSK-15II automatic double clipper can work well and be connected to different fillers for Sausage making. This model is totally stainless steel which will completely meet the hygiene standard of food industrial. It can fix 15-7,15-8,15-9 clipping mould
Its working speed is 0-120 times adjustable, matching with different type Great Wall (Poly Clip) aluminum clips. Thanks to the unique mechanical structure, this double clipping machine is fitted for long time runing at production and with very little maintenance cost.
Features and characters
--- Filling out of all types of pastes into any casing and container with high output and high quality;---Easy connected with various stuffing filling machines to realize automatic production.
--- Quipped with automatic counting and cutting system, about 0-20 ties adjustable.
--- Advanced control system of PLC.
--- Simple one button operation with the pneumatic swing-off and swing-on.
--- Automatic oil lubrication system to make for less impact force and lower noise.
--- Unique design and work mode help on minimum maintenance.
--- Easy change of clip without tools.
--- Double vacuum filling horns system for changing of casing easily.
--- Stainless steel structure and excellent surface treatment make for easy cleaning.
--- Optional accessories: automatic lifting device, high speed twister, filling head, filling flow divider, etc.
Key Parameters
Available clip: aluminium great wall clip 15-8,15-9.
Available casing: 30-120mm (semi perimeter)
Clip speed: 0-200 times/min adjustable
Power: 2.7kw
Voltage: Alternating Current 220V
Air source: working pressure 0.5~0.6Mpa(for cutting knife)
Dimension: L×W×H=1090×930×1900mm
N.W.: 630kg
CSK-15 Ⅱ Sausage Clipping System
Film of Automatic Clipper Series
