Gaming PC;Gaming Desktop Computer;Embedded PC;Barebone System Computer
|
Processor Main Frequency
|
Intel Core i5 8300H (4 core 8 threads, 8M Cache, 2.30 GHz up to 4.00 GHz, TDP: 45W)
Intel Core i5 9300H (4 core 8 threads, 8M Cache, 2.40 GHz up to 4.10 GHz, TDP: 45W) Intel Core i5 9400H (4 core 8 threads, 8M Cache, 2.50 GHz up to 4.30 GHz, TDP: 45W) Intel Core i7 8750H (6 core 12 threads,9M Cache, 2.20 GHz up to 4.10 GHz, TDP: 45W)
Intel Core i7 9750H (6 core 12 threads,12M Cache, 2.60 GHz up to 4.50 GHz, TDP: 45W)
Intel Core i7 9850H (6 core 12 threads,12M Cache, 2.60 GHz up to 4.60 GHz, TDP: 45W)
Intel Core i9 9880H (8 core 16 threads,16M Cache, 2.30 GHz up to 4.80 GHz, TDP: 45W)
Intel Core i9 9980HK (8 core 16 threads,16M Cache, 2.40 GHz up to 5.00 GHz, TDP: 45W)
|
|
Graphics Card
|
Inte UHD Graphics 630
|
|
Dual Display
|
H-DMI maximum resolution (H-DMI 1.4): 4096x2304@24Hz
DP maximum resolution (DP): 4096x2304@60Hz
(DP+H-DMI)Support dual-line Synchronous or Independent display
|
|
Memory(RAM)
|
Support Dual Memory,2* 204-pin SO-DIMM
4GB/8GB/16G/32G DDR4 2400/2666MHz
Max to 64GB(2*32GB) Only one RAM installed by default
Note: If you need 32G DDR4 RAM,please contact us first.
|
|
Hard Disk(SSD)
|
1* Full Height M.2 NVME 2280 SSD Socket+1* M.2 SATA 2242
128GB 256GB 512GB 1TB M.2 SSD |
|
Support System
|
Official Window 10/8 Linux ubuntu CENTOS Openelec, etc.
Notice: we pre-install activated non-genuine version Win7/8/10 OS for free only,; If you need legal genuine Win8/10 OS or other OS like Linux, Ubuntu, Pfsense..., please leave us message.
|
|
Front-Panel Connectors
|
Power on/off,1 x USB 2.0,1 x USB Type-C
|
|
Rear-Panel Connectors
|
1 x H-DMI+1 x DP
1 x Audio, 2 x USB 3.0, 2 x USB 2.0 1 x RJ45 10/100/1000 Mbps Adaptive 1 x DC IN 12V |
|
Ethernet port
|
LAN: RJ45 10/100/1000Mbps RTL8168/8111
|
|
WIFI & BT Supported
|
2 in 1 Module:
WIFI ----NGFF 300M,802.11.b/g/n, 2GHz /5GHz Dual Band
BT-----BT 4.0
|
|
USB Port
|
3x USB 2.0, 2 x USB 3.0,1x USB Type-C
|
|
Audio port
|
Realtek ALC662 Audio Control Chip2 Channels, Stereo, Line out
|
|
Features
|
Supports Wake UP on LAN, S5 RTC Wake Settings, PXE Boot, Restore on AC power loss.
|
|
Extension Options
|
1 x RS232 COM Port, 1 x External 2.5" inch SATA SSD
|
|
Power
|
Power Type: DC-IN5.5*2.5
Power Supply: DC 192V 4.7A/89.3W(AC TO DC,100~240V) |
|
Mounted
|
Desktop
|
|
Chassis Material
|
Aluminum Alloy
|
|
Operating Temperature
|
-20-65℃
|
|
Storage Temperature
|
-20…+85°C(15- 35℃ recommended)
|
|
Relative Humidity
|
5%~95% without condensation
|
|
Dimension
|
150*146*66.5mm
|
