High Speed Balance Bt30 Floating Tap Tool Holders BT30-ER40-70L Coated Machine Tools Accessory
We are Pingyuan Best Machine Tools., Co., Ltd., the high-end cnc machine tools manufacturer and supplier from China. Our products line is over 100
models, mainly include: Collet Chuck , Tool Holder Device , Collet , Spanner , Pull Stud and Nuts , Etc. Collet chuck also include many standards and models like: ISO series, BT30 series, BT40 series, HSK series, NBT series and CAT series, etc.
|
Brand Name |
BESTMYT |
|
Model Number |
BT30-ER40-70L Coated tool holder |
|
Color |
Silver white with nickel film coated |
|
Materials |
20CrMnTi/40Cr Alloyed case hardened steel,black-finished and precisely grind. |
|
Taper tolerance |
<AT3 |
|
Run out accuracy |
≤0.003 mm |
|
Surface Roughness |
>0.8mm |
|
Roundness |
<0.8μm |
|
Carbonizing depth |
08mm±0.2mm |
|
Hardness |
HRC58-62 |
|
Balance |
G2.5 / G6.3 |
|
Quality control |
100% inspection |
|
Warranty |
3 years |
|
Service |
Customized OEM/ODM |
|
Function |
Suitable for drill iron bed, grinder, lathe,process,carving Machine, Engraving and Milling machine etc. |
|
Applicable cutters |
vertical disc cutter, sets of type of milling cutter, face milling cutter, milling cutter, three face milling cutter .Mechanical spindle and cutting tools and other accessories. |
1. Raw materials: Carbonized steel high harden ability, especially high temperature impact toughness under guaranteed harden ability.
2. Production capacity: Optimizing the industrial structure makes our production efficient, cost-effective and very good quality.
If you are interested in the product, contact 2bvideo.com for more information for more information
The information of 2bvideo.com limited shown above is provided by the user or collected on the network. Video 2B does not guarantee the authenticity,accuracy and legitimacy of 2bvideo.com limited information. Video 2B does not involve legal relationships and disputes between users arising from transactions other than secured transactions on this website. Disputes shall be settled by you through negotiation. If you are the person in charge or relevant employee of this enterprise, if you find that the enterprise information is incorrect or want to manage thiscompany, please contact us jacklee1558@gmail.com, after you claim the enterprise, you can obtain management permission, publish supplyand demand information, bring consulting orders, and remove page advertisements.
Main Product:
Collet Chuck and Tool Holder,
ER Collet SK Collet,
Collet Chuck Claw Clamps ,
Tool Holder Loacking Device,
Tool Holder Pull Stud Nut,
Spanner Dust Chip Extraction Nut
