Product details
Insulated Terminals are suitable for the connection of copper conductors(section 1.25-8mm2) in power cable with electronic equipment, they are made of higher 99.99 % pure Copper Lugs T2 and PVC Insulated.Cold-pressed Terminal
The company has more than 95% of the full automatic production lines, nissan 200 tons, production capacity continues to adjust and expand, to meet the challenge of the market at any time.
Through the European CE safety certification, American UL safety certification, the company has a SC Japan JIS standard, the German DIN standards, AWG American standards, etc.
Companies always adhere to: quality first, service first, from raw materials into the factory inspection, process inspection to every working procedure, outbound packaging cengcengbaguan .
Company has own copper pipe, copper strip, copper platoon of raw material processing factory, with strong competitive advantage price on equal quality to every guest get the maximum benefits.


 We are a professional manufacturer with automatic equipment and strong supply capacityThis section describes the certification of copper tube terminalsThis section describes the certification of copper tube terminalsThis section describes the certification of copper tube terminalsApplication field of terminal blocksApplication field of terminal blocksInsulated TerminalsInsulated TerminalsInsulation terminal combination diagramCold-pressed TerminalCombination diagram of thread nose and thread ear
PART NO ITEM NO DIMENSIONS WIRE RANGE
ΦD Φd L l Single mm Twine mm 2 AWG COLOR
LY0032-0001 BF1.25 5.6 2.0 23.0 15.0 0.57-1.44 0.57-1.25 22-16 RED
LY0032-0002 BF2 6.2 2.4 23.5 15.0 1.44-1.82 1.25-2 16-14 BLUD
LY0032-0003 BF5.5 8.1 3.6 25.5 15.0 1.82-2.98 2.65-6.64 12-10 YELLOW
LY0032-0004 BF8 8.5 5.1 35.8 19.2 2.89-3.65 6.64-10.52 8 RED
