52100 cold drawn steel round bar
52100 steel is a high carbon chromium alloy steel with its versatility. In different heat treated conditions, this material can be used in various mechanical application. For example, 52100 annealed steel bars can be easy to be machined. 52100 quenched and tempered steel bars are suitable for applications requiring high hardness, high strength and high fatigue strength for wear resistance.
52100 steel grade is produced by the vacuum-arc melting process, so this grade has good cleanliness and soundness.
The most popular 52100 steel bar includes: annealed bar, bright steel bar, hexagon steel bar and cold drawn steel bar.
52100 steel application:
Anti-friction bearings and rollers, Slitting rolls, spacers and knife blades, seals, sleeves, bushings, tools, dies, moulds, engine and hydraulic parts etc.
The detailed specification of 52100 steel bar:
|
Sizes |
Wide range from 14mm to 100mm |
|
Tolerances |
Precision to h9, h10, h11 or even small to 0.02mm |
|
Roundness |
75% of diameter tolerance |
|
Straightness |
Good straightness to 0.5mm/m |
|
Surface roughness |
Smooth to 0.8um |
|
Mechanical properties |
Yield strength and tensile strength can be improved |
|
Machining |
Suitable for machining and welding |
1. 52100 chemical composition:
|
Elements |
C |
Mn |
Si |
Cr |
Mo |
P |
S |
Cu |
|
GCr15 / 52100 |
0.95-1.05 |
0.25-0.45 |
0.15-0.35 |
1.40-1.65 |
0.10 max |
0.025 max |
0.025 max |
0.25 max |
2. 52100 equivalent material:
|
Standard |
GB/T 18254 |
CNS3014 |
ISO 683/17 |
GOST 801 |
JIS G4805 |
DIN 17230 |
ASTM A295 |
BS 970 |
|
Grade |
GCr15 |
SUJ2 |
100Cr6 |
SH15 |
SUJ2 |
100Cr6 |
52100 |
EN31 |
