SPECIFICATIONS
|
|
|
Sensitivity
|
10.2mV/m/s2 (100mV / g) ± 12%, at 80Hz
|
|
Frequency response
|
10 to 1kHz ± 10%; reference to 80Hz
|
|
Acceleration range
|
245m/s2 (25g) peak, at +25 ℃ when used in the entire temperature range of 176m/s2 (18g) peak
|
|
Amplitude Linearity
|
In 9.8m/s2 to 98m/s2 (1g to 10g) peak Within the range of 2%
|
|
Transverse sensitivity
|
At 80Hz is less than 5% of sensitivity
|
|
Mounted resonant frequency
|
Greater than 5kHz
|
|
Polarity
|
When the direction of movement from the mounting stud to the top connector, the output signal is positive
|
|
Broadband Electrical Noise
|
Less than 0.147m/s2 (0.015g) rms
|
|
Electrical Isolation (Pin to Case)
|
600Vrms
|
|
Mounting Torque
|
2.8N • m (25in-lb)
|
|
Weight
|
71g (2.5oz)
|
|
Housing Material
|
All housing materials are 316 series stainless steel
|
|
Electric connector
|
2-pin Mil-C-5015
|
|
Operating and Storage Temperature
|
-40 ℃ to +85 ℃
|
|
Relative humidity
|
100% relative humidity, non-flooding
|
|
Shock Survivability
|
When a fall from 3 feet to compete polyethylene based film covering on the floor, the sensitivity variation is less than 5%
|
