M25 Diaphragm For Turbo Pulse Valve FP25 DP25
Main Features:
1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change
fluid pressure into drive power.
2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction.
This layer of fabric give tremendous design flexibity.
3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or
require extremely high-strength.
4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force
* No Friction * Wide Pressure Ranges * High Strength
* Low Cost * Simple Design * Versatility
5. EPDM, FKM all available.
Main Dimension of M25 Membrane for Pulse Valve:
Ordering Code of Diaphragm For Turbo Pulse Valve:
|
Ordering code
|
Fitted valve code
|
Valve port size
|
Material
|
|
M25
|
FP20, FM20, FP25, FM25, DP20, DM20, DP25, DM25, EP25, EM25, SQP20, SQM20, SQP25, SQM25, FDP20, FDM20, FDP25, FDM25 |
1''
|
NBR
|
|
M40 & M25
|
FP40, FM40, DP40, DM40, EP40, EM40
|
1-1/2''
|
NBR
|
|
M50 & M25
|
FP55, FM55, SQP50, SQM50, SQP55, SQM55, SQP60, SQM60, SQP65, SQM65 |
2''
|
NBR
|
|
M75 & M25
|
FP65, FM65, SQP75-IN, SQM75-IN, SQP100-IN, SQM100-IN |
3''
|
NBR
|
|
Tips: EPDM, FKM all available.
|
|||
Pictures of Pulse Valve Membrane Production:
More Turbo Type Pulse Jet Valve for you to choose:
 |
 |
 |
| Threaded Type | Submerged Type |
Valve Diaphragm |
 |
 |
 |
|
Solenoid Coil |
Solenoid Armature |
Pulse Controller |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
