FC Freezing Explosive Materials Pulverizer

1.Product Features
1)Freezing Explosive Materials Pulverizer: Optimal retention of aroma and strength, compared with common grinding, where approx.15-43% essential oils are lost, while the loss with cryogenic grinding is minimal(approx.3-10%).
2) Freezing Materials Pulverizer:High grinding fineness, low energy consumption, output is 2-3 times than common grinders.
3) Freezing Explosive Materials Crusher: According to the temperature of material embrittlement point, you can adjust the best crushing temperature, energy saving.
4) Material explosion-proof, anti-oxidation etc.
5) Trouble-free stable processing.

6).Compact structure, small space occupation, low installation power, wide application, and high performance cost.

7). Control system has more choices, such as push button , HMI+PLC and so on.

8). Machine materials : AISISUS304 , AISISUS316L, and other material .

2. FC Freezing Explosive Materials Pulverizer Description:

This FC series Cryogenic Pulverizer Machine using liquid nitrogen to lower the input material temperature to material embrittlement condition firstly, then go to the grinding chamber, the input materials were throughly pulverized through blade wheel's high speed rotating, and the comprehensive force like mutual repeatedly impact, crash, shear and friction between the materials and blades, fluted disc, materials and materials.

Grinded materials will be classified and collected by air screen cone type classifier, the grinded material or powder which have not reached the material fineness degree will go back the grinding chamber for re-grinding, most of the cool air will return back to grinding chamber for recycling usage.
The Freezing Embrittlement Crusher /Freezing Embrittlement Pulverizer is composed of storage pre-frozen cylinder, spiral propeller, low temperature pulverizer, cyclone separator, dust filter and electric cabinet.

3. Main Application:
This machine can be widely used in pharmaceutical, food, chemical, defense, scientific research and industry material crushing, showed toughness at room temperature, especially heat-sensitive substances, fine chemicals, in Western medicine, flora and fauna and, unable to crush the material.

Attention to order

1. When order the FC series Cryogenic Pulverizer, Client need to supply the materials name.

2. When order the FC series Cryogenic Pulverizer, Client need to supply the materials characteristic that include materials HP and so on.

3. When order the FC series Cryogenic Pulverizer, Client need to supply how much kinds materials size need to separated

4. When order the FC series Cryogenic Pulverizer, Client need to supply the each kinds separated materials size.

5. When order the FC series Cryogenic Pulverizer, Client need to decide which kinds steel for machine-304 stainless steel or 316L stainless steel (Erbang also give suggestion for the stainless steel model base the materials HP).

Model	350	450
Grinding powder	7.5kw	45KW
Feeder powder	0.75kw	1.5kw
Working temperature	range from 0-196ºC below zero	range from 0-196ºC below zero
Materials size	60-120mesh (sieve model)	100-300mesh Food and herb medicine:100-300 mesh Rubber and plastic: 60-200 mesh
Capacity	100-300kg	100-600 kg/h
Refrigerant	liquid nitrogen	liquid nitrogen
Material	SUS 304	SUS 304

Crush Temperature of different materials

Item	Pulverizing temperature	Pulverizing fineness(mesh)
Nylon	-80	60-100
Rubber	-70	60-100
Soybean	-120	200-300
Wax	-16	100-150
