Plastic Crusher - Plastic Cryogenic Pulverizer
1. Product Description
The machine (Freezing Pulverizer Machine,Freezing Grinder machine) is composed of storage pre-frozen cylinder, spiral propeller, low temperature pulverizer, cyclone separator, dust filter and electric cabinet.
This FC series Cryogenic Pulverizer using liquid nitrogen to lower the input material temperature to material embrittlement condition firstly, then go to the grinding chamber, the input materials were throughly pulverized through blade wheel's high speed rotating, and the comprehensive force like mutual repeatedly impact, crash, shear and friction between the materials and blades, fluted disc, materials and materials.
Grinded materials will be classified and collected by air screen cone type classifier, the grinded material or powder which have not reached the material fineness degree will go back the grinding chamber for re-grinding, most of the cool air will return back to grinding chamber for recycling usage.
2.Main Features
1) Optimal retention of aroma and strength, compared with common grinding, where approx.15-43% essential oils are lost, while the loss with cryogenic grinding is minimal(approx.3-10%).
2) High grinding fineness, low energy consumption, output is 2-3 times than common grinders.
3) According to the temperature of material embrittlement point, you can adjust the best crushing temperature, energy saving.
4) Material explosion-proof, anti-oxidation etc.
5) Trouble-free stable processing.
6).Compact structure, small space occupation, low installation power, wide application, and high performance cost.
7). Control system has more choices, such as push button , HMI+PLC and so on.
8). Machine materials : AISISUS304 , AISISUS316L, and other material .
9). For the electrical component , we mainly use international brand such as ABB ,Siemens or Schneider.
3. Main Application:
This machine can be widely used in pharmaceutical, food, chemical, defense, scientific research and industry material crushing, showed toughness at room temperature, especially heat-sensitive substances, fine chemicals, in Western medicine, flora and fauna and, unable to crush the material.
Attention to order
1. When order the FC series Cryogenic Pulverizer, Client need to supply the materials name.
2. When order the FC series Cryogenic Pulverizer, Client need to supply the materials characteristic that include materials HP and so on.
3. When order the FC series Cryogenic Pulverizer, Client need to supply how much kinds materials size need to separated
4. When order the FC series Cryogenic Pulverizer, Client need to supply the each kinds separated materials size.
5. When order the FC series Cryogenic Pulverizer, Client need to decide which kinds steel for machine-304 stainless steel or 316L stainless steel (Erbang also give suggestion for the stainless steel model base the materials HP).
|
Model |
350 |
450 |
|
Grinding powder |
7.5kw |
45KW |
|
Feeder powder |
0.75kw |
1.5kw |
|
Working temperature |
range from 0-196ºC below zero |
range from 0-196ºC below zero |
|
Materials size |
60-120mesh (sieve model) |
100-300mesh Food and herb medicine:100-300 mesh |
|
Capacity |
100-300kg |
100-600 kg/h |
|
Refrigerant |
liquid nitrogen |
liquid nitrogen |
|
Material |
SUS 304 |
SUS 304 |
Crush Temperature of different materials
|
Item |
Pulverizing temperature |
Pulverizing fineness(mesh) |
|
Nylon |
-80 |
60-100 |
|
Rubber |
-70 |
60-100 |
|
Soybean |
-120 |
200-300 |
|
Wax |
-16 |
100-150 |
