Fine Salt Industry Mixer
Specialities:
1. VH Series Dry Powder Mixer is Salt Mixing Machine
2. VH Series Dry Powder Mixer has high quality.
4. VH Series Dry Powder Mixer is Fine Salt Mixing Machine
5. VH Series Dry Powder Mixer is Fine Salt Industry Mixing Machine
Fine Salt Mixing Equipment is used for mixing of dry granulate material in pharmaceutical, food-stuff, chemical and other industries.
Product Brief Introduction:
V type high efficient asymmetric mixer, it is suitable for chemical, food, medicine, fodder, ceramics, metallurgy and other industries or granular material. The machine`s structure is reasonable, simple, closed operation, feeding and discharging material conveniently, (artificial or vacuum charging) barrel is made of stainless steel material, easy to clean, and can according to user requirements supporting forced mixer, for thin powder, block, containing certain moisture mixed material.
Principle and structure:
There is one set of motor and reducer at one end of the spiral mixer machine. The motor and reduce are connected by belts.
When the power on, the motor start work to drive reducer work ,The reducer rotate with the coupling to make the barrel rotary continuously, drive material inside the barrel runs up, down, left, right. This will achieve intensive mixing
Main Technical Parameter:
The Main technical datum is for reference. We also produce and design product as per customers' requirement:
| Model of mixing machine | Capacity(m2) | Loading factor | Loading capacity(L) | Rotating speed(r/min) | Motor power(Kw) | Total weight(kg) | Model of vacuum pump |
| VH-0.1 | 0.1 | 0.4 | 40 | 15 | 1.1 | 180 | W2 |
| VH-0.3 | 0.3 | 0.4 | 120 | 15 | 1.5 | 350 | W2 |
| VH-0.5 | 0.5 | 0.4 | 200 | 15 | 1.5 | 550 | SK-1.5 |
| VH-1.0 | 1.0 | 0.4 | 400 | 12 | 3.0 | 1000 | SK-3 |
| VH--1.5 | 1.5 | 0.4 | 600 | 10 | 4.0 | 1100 | SK-3 |
| VH-2.0 | 2.0 | 0.4 | 800 | 10 | 5.5 | 1500 | SK-3 |
| VH-2.5 | 2.5 | 0.4 | 1000 | 8 | 7.5 | 1700 | SK-6 |
| VH-3.0 | 3.0 | 0.4 | 1200 | 6 | 7.5 | 1800 | SK-9 |
