| Product model | 9V4A | 12V3A | 15V2.4A | 18V2A | 24V1.5A | 36V1A |
| Input |
100 - 240V/50 - 60Hz，≤1.0A，≥0.5，≤0.3W
|
|||||
| Efficiency | ≥75% | ≥81% | ≥83% | ≥84% | ≥85% | ≥86% |
| Output |
9±5%V
0 - 4.0A
|
12±5%V
0 - 3.0A
|
15±5%V
0 - 2.4A
|
18±5%V
0 - 2.0A
|
24±5%V
0 - 1.5A
|
36±5%V
0 - 1A
|
| Max transient current | ≤5A | ≤5A | ≤4A | ≤3.6A | ≤2.5A | ≤1.5A |
| Ripple wave | ≤100mV | ≤120mV | ≤150mV | ≤180mV | ≤240mV | ≤360mV |
| Output (max) | 36W | |||||
| Lsolation voltage | ≥3.75KV/5ma/60S | |||||
| Surge voltage | ≥3KV | |||||
| Protection | OVP、OCP、SCP | |||||
| Waterproof grade | IP67 | |||||
| Mean failure - free life | ≥20000H | |||||
| Standard | ETL / FCC / GS / CE / CB / BSMI / CCC / CQC / SAA / KC | |||||
If you are interested in the product, contact 2bvideo.com for more information for more information
