Available for both one/single arm and double arms of Industry Welding Fume Dust Collector
Application
Industry Welding Fume Dust Collector Used for purification of the smoke and dust during the welding, polishing, cutting, grinding process and and other workplaces that generate smoke., can purify large amounts of suspended small metallic particles in the air.
Technical parameters
Model |
LFHY-2000J |
LFHY-2000G |
LFHY-3000 |
LFHY-4000 |
LFHY-5000 |
Power (KW) |
0.75/1.1/2.2 |
1.1/1.5 |
1.5/2.2 |
2.2/3 |
3/5.5 |
Voltage (V) |
220/380 |
220/380 |
220/380 |
220/380 |
380 |
Rotation rate (r/min) |
2840 |
2840 |
2840 |
2840 |
2840 |
Air flow (m³/h) |
1900-2400 |
1900-2400 |
2500-3100 |
3400-4100 |
3800-4600 |
Wind presssure (Pa) |
1350-1240 |
1350-1240 |
1510-1390 |
1720-1580 |
1900-1740 |
Noises (<dB) |
62 |
65 |
70 |
75 |
78 |
Method of installation |
Buckle type rotary assembly |
Buckle type rotary assembly |
Buckle type rotary assembly |
Buckle type rotary assembly |
Buckle type rotary assembly |
Filter Element |
LFHY-3540 |
LFHY-3550 |
LFHY-3550 |
LFHY-3560 |
LFHY-3560 |
Element Qty |
1 |
1 |
2 |
2 |
4 |
Filtration area (m²) |
10 |
10 |
16 |
20 |
36 |
Cleaning control |
NO |
pulse |
pulse |
pulse |
pulse |
Ash removal mode |
NO |
automation |
automation |
automation |
automation |
Air supply |
No |
User provided |
User provided |
User provided |
User provided |
Smoke suction arm size(mm) |
160*2000 |
160*2000 |
160*2000 |
160*3000 |
160*3000 |
Smoke suction arm qty |
1 |
1 |
1 |
2 |
2 |
The whole machine size(mm) |
500*500*1100 |
650*650*1300 |
650*850*13000 |
800*850*1400 |
900*850*1500 |
whole machine weight(kg) |
60 |
75 |
85 |
110 |
130 |
Portable Dust Collector Photo
