pneumatic system filters

2 month ago

1 0

Hongrijia Depurate Facility Science & Technology Co.,Ltd.

 4 year year

Product details

Feature & Benefit

① Connection size range from RC1/2" to RC4" , flow rate from 1.0m³/min to 48m³/min.

② 4000~6000 hours serve life for filter element,filtration performance up to 99%, base on ISO8573.1-2010 Internation Standard
③ 15 years warranty under working condition from temperature 1.5ºC~80ºC.Maxi. Pressure is 1.0Mpa.
④ Lower pressure loss thanks for top cap of filter element with diversion fins, which will let the air come inside the filter more smooth,

7 Grades Filter Element in Detail

PF	AO	AA	AX	ACS	AR	AAR
As a primary filter, particles whose diameter more than 5μm can be remove,the maxi. residual oil content is negligible	High efficiency general protection, dust particles, water mist & oil mist whose diameter more than 1μm can be removed, the residual content of oil mist does not exceed 0.6mg/m³ (21ºC),1ppm(w).	High effiency oil remove filtration, dust particles, water mist and oil mist whose diameter more than 0.01μm can be removed, the residual content of oil mist does not exceed 0.01mg/m³(21ºC),0.01ppm(w)	Ultra-efficient filtration, dust particles, water mist&oil mist whose diameter more than 0.01μm can be removed, the residual content of oil mist does not exceed 0.001mg/m³(21ºC),0.001ppm(w)	Dust particles whose diameter more than 0.01μm, oil vapor &odor can be removed, the maxi. resident content of oil vapor does not exceed 0.003mg/m³(21ºC),0.003ppm(w)	Dust particles whose diameter more than 1μm can be removed	Dust particles whose diameter more than 0.01μm can be removed

International test and measurement standard ISO12500

>ISO 12500 has made clear a general test and definition method for the compressed air filter manufacturers. The main performance
parameters are the air inlet oil content and particles size distribution of the solid particles.
>ISO12500-1 specifies the test requirements for the filtration performance of oil aerosol in the coalescing filter.
>ISO12500-2 specifies the test requirements of adsorption filters for the removal performance of steam adsorption.
>ISO12500-3 specifies the requirements for removal of particulate matter from solid pullutants.

Product are test with the international advanced testing equipment based on standard ISO12500, Which is equivalent to the standard ISO8573.1-2010 quality standard, and provide filter performance test report.

Filtration Grade	PF	AO	AA	AX	ACS	AR	AAR
Size of solid particles(ISO12500-3)	5μm	1μm	0.01μm	0.01μm	-	1μm	0.01μm
Filtration performance of solid particles(ISO12500-3)	-	99.999+%	99.999+%	99.999+%	99.999+%	99.999+%	99.999+%
Filtration performance of oil(ISO12500-1)	50%	80+%	99.9+%	99.99+%	-	-	-
Residual oil content(ISO12500-1)	5mg/m³	0.6mg/m³	<0.01mg/m³	<0.001mg/m³	<0.004mg/m³	-	-

Technical Specification
The flow rate below is the treatment capacity of compressed air under rated working pressure 7 barg (100psi g).
For application in other working pressure, please refer to the correction factors.

Model	Pipe size	Flow rates			Dimension (mm)
Model	Pipe size	L/S	m3/min	scfm	W(Width)	D(Depth)	H(Height)	A	B	C(clearance for housing)
YF010	RC1/2"	16.7	1.0	35.3	96	79	261	29	198	118
YF020	RC3/4"	25.0	1.5	53.0	96	79	261	29	198	118
YF030	RC3/4"	30.0	1.8	63.6	96	79	295	29	233	153
YF040	RC1"	33.3	2.0	71.0	96	79	295	29	233	153
YF060	RC1"	60.0	3.6	127.0	138	111	403	37	296	208
YF070	RC1"	83.3	5.0	177.0	138	111	503	37	396	303
YF080	RC1-1/2"	125.0	7.5	265.0	138	111	503	37	396	303
YF090	RC2"	166.7	10.0	353.1	174	142	736	58	607	469
YF100	RC2-1/2"	216.7	13.0	459.0	174	142	736	58	607	469
YF110	RC2"	283.3	17.0	600.0	174	142	1016	58	887	794
YF120	RC2-1/2"	316.7	19.0	671.0	174	142	1016	58	887	794
YF130	RC3"	416.7	25.0	883.0	220	184	793	74	649	514
YF140	RC4"	466.7	28.0	989.0	220	184	793	74	649	514
YF150	RC3"	683.3	41.0	1448.0	220	184	1050	74	906	764
YF160	RC4"	800.0	48.0	1695.0	220	184	1050	74	906	764
Technical requirements	Maximum operating pressure: 10 barg Operating temperature: 1.5°C~80°C.

Pressure	Barg	1	2	3	4	5	6	7	8	9	10	11	12	13	14	15	16
Pressure	Psig	15	29	44	59	73	87	100	116	131	145	160	174	189	203	219	232
Correction factor		0.38	0.53	0.65	0.76	0.85	0.93	1.00	1.07	1.13	1.19	1.23	1.31	1.36	1.41	1.46	1.51

Replacements & Spare Parts

Successful Cases

YUKA service
a. Providing professional consultation, technical support and special solutions
b. Providing timely feedback on complaints
c. Providing perfect after sales service and warranty

Q:Why choose us?
a. 22 years' practical experiences in R&D and manufacturing Compressed air treatment;
b. Founder of Compressed Air Nation Standard GB/T30475.1-2013 and GB/T30475.2-2013;
c. ISO 9001:2015, CE and product follow ISO8573-1;
d. With Germany Imported high efficiency filtration Test Instrument;
e.All goods had been 100% test before dispatched.

Frequently Asked Questions
Q1. What kind of your company is it?
We're the manufacturer integrated with R&D, production and sales.

Q2. How about your technical conditions and production capability?
Complete process documents and equipment, mass production.

Q3. What is the delivery time?
Delivery time depends on the order quantity, normally is 3-5 working days after 30% payment.

Q4. Do you have a warranty?
Yes, for filter, it is 1 year normally.

Q5. Can you supply customized product?
Yes, we have a professional technical team to provide you with the best solution and complete production processes and control to provide you with satisfied product.
