Stainless Steel air filter are important items of filtration requirements in a compressed air system,which are designed not only to filter oil vapor and water, but also to filter solid particulates to an acceptable level as small as 0.01micron in size. Usually, in the installation system, the first filter's purpose is to pre-filter, protect the high efficiency filters from bulk contamination so as to provide high quality compressed air. If the compressed air filters worked under damp or full of water adsorption condition, it would prevent the compressed air from getting through the filter element and the air low would force the liquid to get through from the pores of the element media. Thus increase working pressure drop and reduce filtration performance.
Feature & Advantage
· 304 & 314 stainless steel material in die-casted integrated technology, housing warranty with 15 years.
· Design for harsh and complex working environment, low maintenance and repaired fee.
· Stainless steel filter element material, double support mesh, prevent second pollution from itself.
· Filtration performance meet ISO8573.1-2010 standard, particle removal accuracy down to 1 micron.
Technical Specification
Model
Connection
Flow rate
Dimension (mm)
L/S
m³/min
scfm
Width (W)
Depth (D)
Height (H)
BHL030
25
25.1
1.5
53.0
150.0
φ76
250
BHL080
40
66.8
4.0
141.2
170.0
φ108
390
BHL145
40
116.9
7.0
247.1
170.0
φ108
530
BHL220
DN65
183.7
11.0
388.3
220.0
φ133
700
BHL260-330
DN80
250.5
15.0
529.5
320.0
φ133
980
BHL360
334.0
20.0
706.0
BHL430
DN80
450.9
27.0
953.1
360.0
φ159
850
BHL620
DN100
467.6
28.0
988.4
360.0
φ159
1080
BHL800
DN100
835.0
50.0
1765.0
420.0
φ219
1180
BHL1000
DN125
1002.0
60.0
2118.0
473.0
φ273
1203
BHL1200
DN125
1336.0
80.0
2824.0
473.0
φ273
1203
BHL1400
DN150
1670.0
100.0
3530.0
530.0
φ325
1280
BHL1600
DN150
2505.0
150.0
5295.0
580.0
φ377
1350
BHL1800
DN200
3340.0
200.0
7060.0
630.0
φ426
1450
BHL2000
DN200
4175.0
250.0
8825.0
BHL2200
DN250
5010.0
300.0
10590.0
720.0
φ500
1550
BHL2400
DN250
5845.0
350.0
12355.0
Technical Requirement
Maxi.pressure:16barg, Maxi.working temperature:80℃, Mini working Temperature : 1.5℃
Pressure
Barg
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Psig
15
29
44
59
73
87
100
116
131
145
160
174
189
203
219
232
Correction factor
0.38
0.53
0.65
0.76
0.85
0.93
1.00
1.07
1.13
1.19
1.23
1.31
1.36
1.41
1.46
1.51
Filter Element Grade
Filtration Grade
PF
AO
AA
AX
ACS
AR
AAR
Size of solid particles(ISO12500-3)
5μm
1μm
0.01μm
0.01μm
-
1μm
0.01μm
Filtration performance of solid particles(ISO12500-3)
-
99.999+%
99.999+%
99.999+%
99.999+%
99.999+%
99.999+%
Filtration performance of oil(ISO12500-1)
50%
80+%
99.9+%
99.99+%
-
-
-
Residual oil content(ISO12500-1)
5mg/m³
0.6mg/m³
<0.01mg/m³
<0.001mg/m³
<0.004mg/m³
-
-
