RS6K-340M
RS6K-340M is a robust solar module with 120 solar cells. These modules can be used for on-grid solar applications. Our meticulous design and production techniques ensure a high-yield, long-term performance for every module produced. Our rigorous quality control and in-house testing facilities guarantee Restar solar's modules meet the highest quality standards possible.
Product Details
* Mono Solar Panel 340W solar power is for solar systems
* High Reliability
Specification
ELECTRICAL DATA(NOCT)
STC: Irradiance 1000% W/m² , Cell Temperature 25°C,Air Mass AM 1.5 according to EN 60904-3
|
Rated Power in Watts-Pmax(wp)
|
325W
|
330W
|
335W
|
340W
|
|
Open Circuit Voltage-Voc(V)
|
41.1V
|
41.3V
|
41.5V
|
41.7V
|
|
Short Circuit Current-Isc(A)
|
10.2A
|
10.31A
|
10.36A
|
10.55A
|
|
Maximum Power Voltage-Vmp(V)
|
33.6V
|
33.8V
|
34.0V
|
34.2V
|
|
Maximum power current-Imp(A)
|
9.68A
|
9.77A
|
9.87A
|
9.96A
|
|
Module Efficiency(%)
|
19.26%
|
19.56%
|
19.85%
|
20.15%
|
MECHANICAL DATA
|
Solar Cells
|
Poly 158.75x79.375mm, 5 Bus bars
|
|
Cell configuration
|
120 Cells (6x20)
|
|
Module dimensions
|
1684x1002x35mm
|
|
Weight
|
19KGS
|
|
Front Cover
|
3.2mm Tempered Glass
|
|
Frame Material
|
Anodized Aluminum Alloy
|
|
J-Box
|
IP67, 3 Diodes
|
|
Cable
|
4mm2(IEC)/12AWG(UL),900mm
|
|
Connectors
|
MC4 or MC4 Comparable
|
|
Standard Packaging
|
30pcs/pallet
|
TEMPERATURE & MAXIMUM RATINGS
Nominal Operating Cell Temperature (NOCT)
45°C±2°C
Temperature Coefficient of Voc
-0.32%/°C
Temperature Coefficient of lsc
0.05%/°C
Temperature Cofficient of Pmax
-0.39%/°C
Operational Temperature
-40~+85°C
Maximum System Voltage
1500V(IEC)
Max Series Fuse Rating
20A
PACKAGING CONFIGURATION
40HQ
Number of modules per container
896 pcs
Package
30pcs/pallet, 2pcs/carton
Package Number
28pallets + 28cartons
Resun Solar was founded in 2007, specializes in providing high quality and highly cost-effective solar modules with 1GW production capacity every year, full ranges of Resun panels are certified by TUV IEC61215, IEC61730, VDE, CEC, EMC, LVD, CE and approved PID free by PI-Berlin lab and insured by American CHUBB Insurance Group.Resun Solar has more than 10 years experiences as qualified solar home system supplier for World Bank solar project, in the name of two own brands and seven office and warehouses, the projects distributes in most of Europe Countries, Australia, Canada, South America, Africa, Middle East and Asia etc.
Sales and Service Network
Headquartered in China, Resun 's sales network covers more than 20 Countries, providing customers with instant after sales service and an efficient supply-chain, our clients can be found throughout the world, such as North America, Europe, Oceania, Eastern Europe, East Asia, Middle Easter and Africa etc.
