RS6C-P
Product Details
Specification
ELECTRICAL DATA(NOCT)
STC: Irradiance 1000% W/m² , Cell Temperature 25°C,Air Mass AM 1.5 according to EN 60904-3
Rated Power in Watts-Pmax(wp)
260W
265W
270W
275W
280W
285W
290W
Open Circuit Voltage-Voc(V)
39.85V
37.8V
37.9V
38.1V
38.2V
38.3V
38.4V
Short Circuit Current-Isc(A)
8.95A
9.01A
9.76A
9.32A
9.40A
9.49A
9.59A
Maximum Power Voltage-Vmp(V)
30.3V
30.3V
30.7V
31.1V
31.4V
31.6V
31.8V
Maximum power current-Imp(A)
8.58A
8.69A
8.79A
8.84A
8.92A
9.02A
9.12A
Module Efficiency(%)
16.01%
16.32%
16.60%
16.80%
17.10%
17.40%
17.83%
ELECTRICAL DATA(NOCT)
NOCT:Irradiance at 800 W/m²,Ambient Temperature 20°C,Wind Speed 1 m/s.
Maximum Power-Pmax (Wp)
192W
195W
198W
204W
208W
211W
215W
Open Circuit Voltage-Voc(V)
34.9V
35.1V
35.4V
35.3V
35.4V
35.5V
35.6V
Short Circuit Current-Isc(A)
7.20A
7.24A
7.29A
7.52A
7.59A
7.66A
7.74A
Maximum Power Voltage-Vmp(V)
28.1V
28.3V
28.5V
28.8V
29.0V
29.2V
29.4V
Maximum power current-Imp(A)
6.82A
6.89A
6.95A
7.09A
7.15A
7.23A
7.31A
MECHANICAL DATA
|
Solar Cells
|
Poly 156x156mm, 5 Bus bars
|
|
Cell configuration
|
60 cells(6x10)
|
|
Module dimensions
|
1640x992x35mm
|
|
Weight
|
19KGS
|
|
Front Cover
|
3.2mm Tempered Glass
|
|
Frame Material
|
Anodized Aluminum Alloy
|
|
J-Box
|
IP67
|
|
Cable
|
4mm2(IEC)/12AWG(UL).900mm
|
|
Connectors
|
MC4 or MC4 Comparable
|
|
Standard Packaging
|
30pcs/pallet
|
|
Nominal Operating Cell Temperature (NOCT)
|
45°C±2°C
|
|
Temperature Coefficient of Voc
|
-0.32%/°C
|
|
Temperature Coefficient of lsc
|
0.05%/°C
|
|
Temperature Cofficient of Pmax
|
-0.39%/°C
|
|
Operational Temperature
|
-40~+85°C
|
|
Maximum System Voltage
|
1500V(IEC)600V(UL)
|
|
Max Series Fuse Rating
|
15A
|
|
Limiting Reverse Current
|
15A
|
|
|
20GP
|
40HQ
|
|
Number of modules per container
|
360pcs
|
924pcs
|
|
Package
|
30pcs/pallet
|
30pcs/pallet, 2pcs/carton
|
|
Package Number
|
12pallets
|
28pallets+42cartons
|
Resun Solar Energy Co., Ltd was founded in 2007,engaged in developing and manufacturing PV solar products with capcity 1GW/Year. The series of the solar energy products are of high quality, easy installation, long life time, free maintenance, low operation cost and environmental friendless.
Certifications
Sales and Service Network
Headquartered in China, Resun 's sales network covers more than 20 Countries, providing customers with instant after sales service and an efficient supply-chain, our clients can be found throughout the world, such as North America, Europe, Oceania, Eastern Europe, East Asia, Middle Easter and Africa etc.
