Product Overview

RS6I-370P

RS6I-370P  is a robust solar module with 144 solar cells. These modules can be used for on-grid solar applications. Our meticulous design and production techniques ensure a high-yield, long-term performance for every module produced. Our rigorous quality control and in-house testing facilities guarantee Restar solar's modules meet the highest quality standards possible.


Product Details



* Poly Solar Panel 370W solar power is for solar systems

* High Reliability

Multi-busbar technology can effectively reduce the reliability risk caused by cells cracks and broken busbar.
* Anti-PID Resistance
Prominent an↑l PIO performance reduces the power degradation, leading to higher energy yield and lower LCOE.
* Durability Against Extreme Conditions
Certified to resist high salt mist and ammonia conditions.
* High Efficiency
Multi-busbar technology can reduce the module internal power loss to improve the module conversion efficiency significantly.









Specification


ELECTRICAL DATA(NOCT)


STC: Irradiance 1000% W/m² , Cell Temperature 25°C,Air Mass AM 1.5 according to EN 60904-3


Rated Power in Watts-Pmax(wp)
355W
360W
365W
370W
Open Circuit Voltage-Voc(V)
47.34V
47.58V
47.81V
48.06V
Short Circuit Current-Isc(A)
9.61A
9.68A
9.75A
9.82A
Maximum Power Voltage-Vmp(V)
39.01V
39.26V
39.50V
39.74V
Maximum power current-Imp(A)
9.10A
9.17A
9.24A
9.31A
Module Efficiency(%)
17.64%
17.89%
18.14%
18.39%



MECHANICAL DATA

Solar Cells
POLY ,half-cell,158.75mmx79.375mm,
Cell configuration
144 Cells (6x24)
Module dimensions
2008mmx1002mmx35mm
Weight
22.5KGS
Front Cover
3.2mm Tempered Glass
Frame Material
Anodized Aluminum Alloy
J-Box
IP67 orIP68, 3Diodes
Cable
4mm2(IEC)/12AWG(UL),900mm
Connectors
MC4 or MC4 Comparable
Standard Packaging
31pcs/pallet


TEMPERATURE & MAXIMUM RATINGS

Nominal Operating Cell Temperature (NOCT)
    45°C±2°C
Temperature Coefficient of Voc
    -0.32%/°C
Temperature Coefficient of lsc
     0.05%/°C
Temperature Cofficient of Pmax
     -0.39%/°C
Operational Temperature
     -40~+85°C
Maximum System Voltage
     1500V(IEC)
Max Series Fuse Rating
     20A



PACKAGING CONFIGURATION


40HQ
Number of modules per container
726 pcs
Package
31pcs/pallet, 2pcs/carton
Package Number
22pallets+22cartons




Company Profile

Resun Solar was founded in 2007, specializes in providing high quality and highly cost-effective solar modules with 1GW production capacity every year, full ranges of Resun panels are certified by TUV IEC61215, IEC61730, VDE, CEC, EMC, LVD, CE and approved PID free by PI-Berlin lab and insured by American CHUBB Insurance Group.Resun Solar has more than 10 years experiences as qualified solar home system supplier for World Bank solar project, in the name of two own brands and seven office and warehouses, the projects distributes in most of Europe Countries, Australia, Canada, South America, Africa, Middle East and Asia etc.




3 Our Workshop


4 Certification

Sales and Service Network


Headquartered in China, Resun 's sales network covers more than 20 Countries, providing customers with instant after sales service and an efficient supply-chain, our clients can be found throughout the world, such as North America, Europe, Oceania, Eastern Europe, East Asia, Middle Easter and Africa etc.
