Model T and Q Skid pump sent to China Oilfiled

Model T and Q Skid pump sent to China Oilfiled

2 year ago

55 0

Henan Youlong Petroleum Engineering Technology Co.,Ltd

 4 year year

Product details

T190（3W125）Triplex Plunger/Piston Pump

The YouLong Model T190 is a single acting triplex plunger/piston pump rated at 190HP in continuous duty services and up to 219HP in intermittent duty. This versatile pump is offered with a variety of material and design options that make it ideal for general industrial, reverse osmosis, and typical applications involved in the production of oil and natural gas.

Specifications
	English Units	Metric Units		Continuous	Intermittent
Stroke Length		125 mm	Rated bhp	190 HP	219 HP
Rated Rod Load	13007 lb	5900 Kg	Maximum Speed	350 rpm	400 rpm
Pump Weight	3750 lb	1700 Kg	Minimum Speed	90 rpm	75 rpm
Oil Capacity	12.6 gal	48 L	Max. plunger size x stroke length.	137x125mm
Max. Fluid Temp	752°F	400°C	Crankshaft extension Dia.x length	100x200 mm
Mechanical Efficiency		90%	Keyway (width x depth x length)	28x10x180 mm

Performance Ratings（Volumes indicated are displacement of incompressible fluid）

plunger		L/RPM	Gal/ RPM	Max.Press.		pump speed=90RPM			pump speed=150RPM			pump speed=200RPM			pump speed=250RPM			pump speed=350RPM			pump speed=400RPM
mm	in	L/RPM	Gal/ RPM	Mpa	Psi	LPM	GPM	M3/h	LPM	GPM	M3/h	LPM	GPM	M3/h	LPM	GPM	M3/h	LPM	GPM	M3/h	LPM	GPM	M3/h
34	1.34	0.340	0.090	63.0	9135	30.6	8.1	1.8	51.0	13.5	3.1	68.1	18.0	4.1	85.1	22.5	5.1	119.1	31.5	7.1	136.1	36.0	8.2
38	1.50	0.425	0.112	50.0	7250	38.3	10.1	2.3	63.8	16.8	3.8	85.0	22.5	5.1	106.3	28.1	6.4	148.8	39.3	8.9	170.0	44.9	10.2
43	1.69	0.544	0.144	40.0	5800	49.0	12.9	2.9	81.6	21.6	4.9	108.9	28.8	6.5	136.1	35.9	8.2	190.5	50.3	11.4	217.7	57.5	13.1
48	1.89	0.678	0.179	32.0	4640	61.0	16.1	3.7	101.7	26.9	6.1	135.6	35.8	8.1	169.6	44.8	10.2	237.4	62.7	14.2	271.3	71.7	16.3
54	2.13	0.858	0.227	25.0	3625	77.3	20.4	4.6	128.8	34.0	7.7	171.7	45.4	10.3	214.6	56.7	12.9	300.4	79.4	18.0	343.4	90.7	20.6
61	2.40	1.095	0.289	20.0	2900	98.6	26.0	5.9	164.3	43.4	9.9	219.1	57.9	13.1	273.8	72.3	16.4	383.4	101.3	23.0	438.1	115.7	26.3
68	2.68	1.361	0.360	16.0	2320	122.5	32.4	7.4	204.2	53.9	12.3	272.2	71.9	16.3	340.3	89.9	20.4	476.4	125.9	28.6	544.5	143.8	32.7
77	3.03	1.745	0.461	12.5	1813	157.1	41.5	9.4	261.8	69.2	15.7	349.1	92.2	20.9	436.3	115.3	26.2	610.9	161.4	36.7	698.1	184.4	41.9
86	3.39	2.177	0.575	10.0	1450	195.9	51.8	11.8	326.6	86.3	19.6	435.4	115.0	26.1	544.3	143.8	32.7	762.0	201.3	45.7	870.9	230.1	52.3
96	3.78	2.713	0.717	8.0	1160	244.2	64.5	14.6	406.9	107.5	24.4	542.6	143.3	32.6	678.2	179.2	40.7	949.5	250.8	57.0	1085.2	286.7	65.1
109	4.29	3.497	0.924	6.3	914	314.8	83.2	18.9	524.6	138.6	31.5	699.5	184.8	42.0	874.4	231.0	52.5	1224.1	323.4	73.4	1399.0	369.6	83.9
137	5.39	5.525	1.460	4.0	580	497.3	131.4	29.8	828.8	218.9	49.7	1105.0	291.9	66.3	1381.3	364.9	82.9	1933.8	510.9	116.0
Brake Horsepower Required						49.4			82.3			109.7			137.2			192（Continuous work）			219.5

*Flows are based on 100% volumetric efficiency. Brake Horsepower /Kilowatts Required is based on 90% Mechanical Efficiency. Consult YouLong for continuous service speeds in excess of 350RPM. Not all plunger sizes are shown,

Additional plunger sizes are available. Please contact YouLong for more details. Standard configuration is a single extended crank, double extending

crank shaft please contact youLong. Discharge and Suction Connection mode and size please contact YouLong.

The information and data on this sheet is accurate to the best of our knowledge and belief, but are intended for general

information only. Applications suggested for the materials are described only to help readers make their own evaluations and

decisions, and are neither guarantees nor to be construed as express or implied warranties of suitability for these or other

applications. YouLongmakes no warranty either express or implied beyond that stipulated in YouLong Standard Terms and

Conditions of Sale.
