2-color pyrometer, also known as ratio infrared pyrometer. It uses the ratio of the infrared radiation energy of the two wavelengths in the adjacent channel to determine the temperature. There is a linear relation between the ratio and temperature, the relationship is determined by the performance of the detector.
These series industrial pyrometer is not only suitable for temperature measurement in general industrial occasions, but also suitable for precise measuring of small targets at long distance, materials with easy changing emissivity, and in occasions with strong attenuation.
In two-color temperature measurement, temperature will not change with the object’s surface state (such different surface roughness or chemical state ), which will not affect the accuracy of temperature measurement, but will have an impact on one-color pyrometer measurement .
The optical part of pyrometer, such as glass, will accumulate some dust after using for a period. The presence of water, gas, oil, etc. in the air will reduce the emissivity coefficient, so the temperature measured by one color pyrometer will decrease. The two-color pyrometer measures the ratio of infrared radiation intensities of two band wavelength in a specific range. With dust, water vapor and other disturbances, the signals of two wavelength fall simultaneously and the ratio remains constant after division. But this does not mean two-color pyrometer does not require maintenance. User still need to wipe the glass when it is too dirty.
STRONG series 2C infrared pyrometer can meet the requirements of two color measuring in various industrial occasions. For example, medium-high temperature below 2000℃, such as: wire rod, hot rolled plate, forging, casting, cement kiln, heat treatment, induction heating, monocrystalline silicon and polycrystalline silicon, etc. It can also be used in ultra-high temperature below 3000℃ measuring, such as vacuum furnace, graphite furnace, high-temperature furnace etc. Measurement has high stability.
Measuring range：700℃～3000℃
Detector：Si/Si（Laminated silicon）
Distance coefficients：60：1
Measuring Distance：Standard Focus length：0.35m adjustable to infinity，Near focus distance：0.2m～0.5m
Accuracy：±0.5%T℃（T is measured temperature）
Resolution：0.1℃
Repeat Accuracy：±2℃
Response time：Fasted 5ms, adjustable in 5ms-99.99s
Wavelength1：（0.7～1.08）μm
Wavelength 2：1.08μm
Hot rolled steel, wire rod, metal forging, casting, induction heating, melting glass, cement kiln, semiconductor, vacuum furnace etc.
Standard：0.35m adjustable to infinity，
Near focus distance：0.2m～0.5m
Model
STRONG-SR-7030
Measuring Range
600℃～1800℃
Detector
Si/Si
One-color mode Wavelength
1.08μm
Two-color mode Wavelength
Applications
Distance coefficients
60：1
Focal length
Accuracy
±0.5%T℃（T is measured temperature）
Resolution
0.1℃
Repeat Accuracy
±2℃
One-color mode: Calibration coefficient
0.100～1.000, Adjustable in 0.001 increments
Two-color mode: Calibration coefficient
0.850～1.150, Adjustable in 0.001 increments
Response time
Fasted: 5ms，adjustable in 5ms-99.99s
Display mode
Industrial-grade self-luminous OLED display screen
Aiming method
Visual green spot (default) or eyepiece aiming, alternative
IP Rating
IP65
