LMSF Serious Mechanical Filter
Brief introduction
Serious Type Speed Filter Is Designed By The Anshan Ministry Of Metallurgical Mining Design Institute Of Ferrous Metallurgy, Which Summarizes Years Of Design And Operation Of Mining Experience, Absorb The Latest Technological Achievements. For Circulating Water Supply Systems, As By Pass Filter Equipment And Filtration Devices For Raw Water Turbidity ≤20mg / l. It Ensures Water Quality With Large Capacity, Small Footprint, Highly Appropriate Advantages Compared To Other Normal Filter.
Working Principle
Taking Advantage of Its Upper Anthracite Packing and Down Quartz Sand Or Cobblestone to Form Separated Filtering Layer thus to Separated Oil and Grease after Float ion and Purify Suspend Solid Under Sequence Auto Back Washing to make the filter as a Filtering Bed
Feature and Characteristic
-Compact Structure Design
-Large Treated Capacity
-High Speed Filtration
-Small Footprint
-Easy Operation and Running
-High Accuracy of Filtration
-Not Easy to Happen Fault
-Lower Investment
-Air Water Mixed Auto Back Flushing with Average Air Distribution
-Can Realized Multiple Sets Auto Controlled Integration
Applicant
-Metallurgical Waste Water Treatment
-Chemical Waste Water treatment
-Light Industry Factory Wastewater Treatment
-Mining Waste Water Treatment
-Steel Factory Waste Water Purification
-Bypass Filtration in Circulating System of Waste Water Treatment
Parameter and Model Selection
|
Model |
MSF-800 |
MSF-1200 |
MSF-1600 |
MSF-2000 |
MSF-2600 |
MSF-3000 |
|
Inlet Area(m2) |
0.50 |
1.13 |
2.0 |
3.14 |
5.3 |
7.07 |
|
DN (MM) |
800 |
1200 |
1600 |
2000 |
2600 |
3000 |
|
Speed |
10-25 |
10-25 |
10-25 |
10-25 |
10-25 |
10-25 |
|
Max. Volume |
12.5 |
28.25 |
50 |
78.5 |
132 |
176.25 |
|
H (mm) |
3400 |
3600 |
3800 |
4200 |
4600 |
4800 |
|
N.W. (KG) |
1.44 |
1.92 |
3.12 |
5.28 |
6.80 |
9.2 |
|
G.W. (KG) |
5 |
10 |
18 |
20 |
33 |
43 |
|
Max. Water Pressure |
≤0.4Mpa |
|||||
|
RW Quality |
S.S. |
≤80mg/L |
||||
|
Oil |
≤10-20mg/L |
|||||
|
Outlet Water Quality |
S.S. |
≤10mg/L |
||||
|
Oil |
≤7mg/L |
|||||
|
Backwashing Data |
Pressure |
0.15Mpa |
||||
|
Air Pressure |
0.07Mpa |
|||||
|
Ave. Water Head Lost |
0.5MPA |
|||||
Design Basic Data
1.Working Temperature∶3～50℃;
2. Max. Running Speed∶25m/h;
3.Max. Running Pressure∶≤0.6MPa;
4.Backwashing Way∶Compressed Air with Water
5.Backwashing Water Pressure∶0.15MPa;
6.Backwashing Water Strength∶20M3/m².h;
7.Backwashing Air Pressure∶0.07MPa-0.1MPa
8.Backwashing Air Strength∶15m/min.h;
9.Backwashing Time∶5～10min;
10.Packing Layer Height∶1500~2000mm;
