Space saving: integrated design of dryer, filter, gas-water separator and suction dryer, saving space;
Energy saving: The design of three-in-one aluminum alloy heat exchanger minimizes the process loss of cooling capacity and improves the recycling of cooling capacity. Under the same processing capacity, the total red and green input of the modified model will be reduced by 15-30
High efficiency: the integrated heat exchanger is equipped with diversion fins, which is the uniform heat exchange of compressed air inside, and the built-in gas-water separation device is equipped with a stainless steel filter screen to separate the moisture more thoroughly.
Intelligent: Multi-channel temperature and pressure monitoring, real-time display of dew point temperature, automatic recording of accumulated running time, self-diagnosis function, display of corresponding alarm codes, and automatic protection of equipment.
Environmental protection: Corresponding to the international Montreal agreement, this series of models all use R134a, R410a, R407c environmentally friendly refrigerants, and the degree of damage to the atmosphere is zero, adapting to international market needs;
Stability: Standard configuration constant pressure expansion valve, standard configuration intelligent temperature control, laboratory test when the temperature reaches 65 ℃, ambient temperature reaches 42 ℃, flammable and stable operation, at the same time with temperature and pressure dual anti-freeze protection When the time is low, the output of the compressor is automatically stopped, and the aluminum plate is used to exchange the stored cooling capacity to provide heat exchange and energy saving, while extending the service life of the equipment.
The following products are suitable for use at 220V 50HZ, 380V 50Hz voltage, other voltages can be customize.
Model
Flow Rate m³/min
Dew Point ℃
Power
Input power KW
Connection
Maxi.Pressure Loss Mpa
Noise
G.W.(KG)
Dimension(MM)
HLX010-20
1.2
-20
220V50Hz
0.5
RC3/4"
≤0.035
≤ 75 dB（A）
100
1200*660*1000
HLX020-20
2.2
-20
220V50Hz
0.65
RC3/4"
≤0.035
≤ 75 dB（A）
128
1200*800*1100
HLX030-20
3.6
-20
220V50Hz
0.86
RC1"
≤0.035
≤ 75 dB（A）
186
1200*800*1100
HLX060-20
6.5
-20
220V50Hz
1.39
RC1-1/2"
≤0.035
≤ 75 dB（A）
265
1500*1000*1100
HLX080-20
8.5
-20
220V50Hz
2
RC2"
≤0.035
≤ 75 dB（A）
288
1500*1000*1600
HLX100-20
11
-20
220V50Hz
2.56
RC2"
≤0.035
≤ 75 dB（A）
368
1500*1000*1600
HLX120-20
13.5
-20
220V50Hz
2.76
RC2"
≤0.035
≤ 75 dB（A）
450
1500*1000*1700
HLX150-20
17
-20
380V50Hz
3.13
DN50 Flange
≤0.035
≤ 75 dB（A）
550
2200*1700*1700
HLX200-20
22
-20
380V50Hz
3.83
DN65 Flange
≤0.035
≤ 75 dB（A）
1050
2200*1700*1800
HLX010-40
1.15
-40
220V50Hz
0.5
RC3/4"
≤0.035
≤ 75 dB（A）
100
1200*660*1000
HLX020-40
2
-40
220V50Hz
0.65
RC3/4"
≤0.035
≤ 75 dB（A）
128
1200*800*1100
HLX030-40
3.3
-40
220V50Hz
0.86
RC1"
≤0.035
≤ 75 dB（A）
186
1200*800*1100
HLX060-40
6.2
-40
220V50Hz
1.39
RC1-1/2"
≤0.035
≤ 75 dB（A）
265
1500*1000*1100
HLX080-40
8
-40
220V50Hz
2
RC2"
≤0.035
≤ 75 dB（A）
288
1500*1000*1600
HLX100-40
11
-40
220V50Hz
2.56
RC2"
≤0.035
≤ 75 dB（A）
368
1500*1000*1600
HLX120-40
12
-40
220V50Hz
2.76
RC2"
≤0.035
≤ 75 dB（A）
450
1500*1000*1700
HLX150-40
16
-40
380V50Hz
3.13
DN50 Flange
≤0.035
≤ 75 dB（A）
550
2200*1700*1700
HLX200-40
20
-40
380V50Hz
3.83
DN65 Flange
≤0.035
≤ 75 dB（A）
1050
2200*1700*1800
HLX010-70
1.15
-70
220V50Hz
0.5
RC3/4"
≤0.035
≤ 75 dB（A）
100
1200*660*1000
HLX020-70
2.3
-70
220V50Hz
0.65
RC3/4"
≤0.035
≤ 75 dB（A）
128
1200*800*1100
HLX030-70
3.6
-70
220V50Hz
0.86
RC1"
≤0.035
≤ 75 dB（A）
186
1200*800*1100
HLX060-70
5.6
-70
220V50Hz
1.39
RC1-1/2"
≤0.035
≤ 75 dB（A）
265
1500*1000*1100
HLX080-70
8.5
-70
220V50Hz
2
RC2"
≤0.035
≤ 75 dB（A）
288
1500*1000*1600
HLX100-70
11
-70
220V50Hz
2.56
RC2"
≤0.035
≤ 75 dB（A）
368
1500*1000*1600
HLX120-70
13.8
-70
220V50Hz
2.76
RC2"
≤0.035
≤ 75 dB（A）
450
1500*1000*1700
HLX150-70
17
-70
380V50Hz
3.13
DN50 Flange
≤0.035
≤ 75 dB（A）
550
2200*1700*1700
HLX200-70
20
-70
380V50Hz
3.83
DN65 Flange
≤0.035
≤ 75 dB（A）
1050
2200*1700*1800
Rated air pressure: 0.7Mpa, max. 1.0Mpa.
General requirements for compressed air intake conditions
Solid particle grade: Grade 7 and above specified in GB/T13277.1-2008
Oil content grade: Level 4 and above specified in GB/T13277.1-2008
