ZJ30 (XJ750hp 3000m) rigs

ZJ30 (XJ750hp 3000m) rigs

10 month ago

35 0

Henan Youlong Petroleum Engineering Technology Co.,Ltd

 4 year year

Product details

Oilfield ZJ40/2250J Drilling Rig

Product introduction

All the rig's systems of power,drawworks,mast,traveling block and transmission system are equipped to the self-proplled chassis.The rig is easy and low cost to be transported,and it has reliable performance,large working load and good off-road power. The basi parameters and overall design conform to the APl standard and HSE system. Adopt mature,reliable,practical and advanced technology.Key components of diesel engine,transmission case and so on are selected imported components.

Over 4 decades,We have been specializing in drilling rig matching and production,and can provide ZJ90,ZJ70,ZJ50,ZJ40,ZJ30 drilling rig and related accessories that fully conform to API standard,including the drill,top drive,BOP blowout preventer,manifold system,compound drill pipe,drill pipe,drill collar,drilling tools,commuter transport vehicles,the lifting cranes and excavators,generator set etc.

ZJ40/2250J rig is block substructure with K type mast, adopts 3 sets of PZ12V190B diesel engines to drive all devices. Main Drawworks and compounding transmission set are placed on 1m high rear substructure, and the rotary table is placed on 6m high drill floor. Belt compounding transmission device drives Drawworks by chain, drive to rotary table through dynamic bevel gear

box and cardan shaft. Belt compounding transmission device drives mud pump by belt.

The rig is the best alternative product of Daqing 130 rig.

Characteristics and features

▲Substructure adopts the modular mode, and blocks connect with each other by pins, which can realize to move quickly.

▲Mast is front open-face, “K” type mast. The five sections of mast is tower-type integral structure, can install with the crown block to transport together. The supporting leg is located at base of substructure. stability is good, It is raised and laid down by drawworks power as a whole.

▲Transfer power though the bevel angle gearbox and the cardan shaft, and the rotary table power is from the cat head winches chain box and cardan shaft, the structure is simple and easy to install. Drawworks is divided, the main of which is placed under drill floor, it adopts sealing structure, chain is force-feed lubrication, pneumatic tyre gear change and drum grooving.

Specifications and parameters

Nominal drilling depth(114mm DP)	2500～4000m	Open diameter of rotary table	φ700mm (27.5")
(127mmDP)	2000～3200m	Qty.× power of diesel engine	3×800kW
Max.hook load	2250kN	Shift of Drawworks	4+2R
Traveling system	5×6	Height of substructure	6m
Dia of Drill line	φ32mm	Mast type and height	K type, 43m
Qty.× power of mud pump	2×1300hp	Drawworks power	735kW（1000hp）
Drive type	belt compound	Mud high pressure manifold	Φ102mm（dia）×35MPa
Rotary table gears	2 shaft stepless speed regulation	Effective capacity of mud tank of solid control system	≥180m3

FAQ

Q1. Why choose us ?

1. Competitive price: our company is a professional supplier of Cementing and Fracturing Equipment, Gate Valve and Wellhead Christmas Tree, Plunger Pumps and Mud Pumps, Flow line Products, Solid Control Equipment, Drilling Rigs and Work over Rigs Matching Equipment etc. We have competitive prices and best resources in advanced production line and testing equipment, designed and manufactured according to certification of API, ISO, GOST, etc.

2. Fast delivery: the delivery time of all our machines is very fast, especially the popular Plunger Pumps and Mud Pumps, Flow line Products.

3. Warranty: after sales service is very important for construction machinery. Our company provides warranty for all machinery purchased from us. During the warranty period, we will accurately confirm the damaged parts in the shortest time and send the replacement parts to the customers by DHL or air freight in the most efficient way.

Q2. How can you guaranteed quality?

On the basis of more than 40 years of manufacturing experience,more than 30 years of export experience, high quality products with competitive price, better understanding in Chinese market, High quality after-sales service, we hope to establish business relations with your company.

Q3. Can you satisfy my special requirement?

As the manufacturer, Youlong will review the special requirement and recondition it as per request (if possible).

Q4. How about your technology after-service team available?

We have postgraduated engineer and repair machines team, and worked inconstructions machine area almost 20 years. We could give you service support on line on time, or send to Machinican to support on necessary.
