Our company focuses on construction machinery and energy equipment, with a wide range of machinery suitable for various scenarios.
Diesel generator set is a common power generation equipment, which has a wide range of applications in various occasions
30kW generator set is an efficient and reliable power generation equipment, which is widely used in various industrial and civil fields. This generator set adopts advanced design concept and has a variety of excellent features to meet the power demand in different scenarios.
In terms of performance, the 30kW generator set has excellent power generation capacity and stability. It uses high-quality engines and generators to achieve efficient energy conversion through precise matching and optimization. At the same time, the generator set also has low noise and vibration levels, ensuring that the surrounding environment will not be disturbed during operation.
In terms of reliability, the 30kW generator set has undergone rigorous testing and inspection to ensure stable operation in a variety of harsh environments. Its rugged housing and internal components can effectively resist the erosion of natural factors such as wind, sand and rain. In addition, the generator set is equipped with an intelligent control system, which can monitor the operating status in real time and detect and deal with potential problems in a timely manner.
In terms of application fields, 30kW generator sets are widely used in construction sites, mines, ships, oil fields and other scenarios. It can provide stable power support for various equipment to ensure the smooth progress of the project. At the same time, in the case of power failure or emergency, the generator set can also be used as a backup power supply to ensure the normal operation of key equipment.
In short, the 30kW generator set is an excellent, reliable and durable power generation equipment that can meet the power needs of various industrial and civil sectors. Whether in construction sites, mines or ships and other scenes, it can play an excellent role in providing stable power protection for people's production and life.
Diesel generator set consists of:
|
Diesel power generator set data |
|||
|
model |
30GF |
Main power of the unit (KVA / KW) |
37.5/30 |
|
Unit Standby power (KVA / KW) |
42/33 |
Rated output current (A) |
54 |
|
output voltage (V) |
400/230 |
power factor |
0.8 (Lag) |
|
mode of connection |
Three phase four line |
frequency (Hz) |
50 |
|
starting mode |
24V DC start |
Unit size (length, width and height) |
1600×680×1200mm |
|
Unit Weight (kg) |
600 |
||
|
Diesel engine data |
|||
|
manufacturer |
Weichai Shares (Rui Power) |
model |
WP2.3D40E200 |
|
Rated rotation speed (Rpm) |
1500 |
Engine power (KW) |
40 |
|
number of cylinders |
4 |
Cylinder arrangement |
in-line arrangement |
|
Cylinder diameter stroke (mm) |
89×92 |
discharge rate |
2.3 |
|
Intake mode |
Natural intake |
reduction ratio |
17.5：1 |
|
fuel oil |
China 0 # light diesel oil |
100% load fuel consumption (G / KW.h） |
258 |
|
lubricating oil specification |
15W/40CD |
Lubricating oil consumption (L/h) |
And 0.5% fuel consumption |
|
Total lubricant capacity (L) |
13 |
Coolant Capacity (L) |
5 |
|
Engine cooling mode |
Meet the ambient temperature of 40℃ radiator, belt-driven cooling fan, with fan safety cover |
||
If you are interested in the product, contact 2bvideo.com for more information for more information
