Delrin 100AF blend is a POM homopolymer with special PTFE fibers designed to optimize the material's sliding friction properties. The fibers are homogeneously distributed in the acetal material, which results in improved slide-friction performance and abrasion resistance, coupled with minimal susceptibility to stick-slip effects. Furthermore, the POM-H AF provides good creep strength and extremely good dimensional stability. Delrin is a registered trade mark of Delrin USA LLC.
DELRIN® 100 AF blend stock shapes are 13% PTFE fiber filled homopolymer acetal. They offer an improved coefficient of friction, better lubricity, and improved wear characteristics over unfilled and PTFE powder filled acetals. This advanced acetal material uses a combination of PTFE fibers uniformly dispersed in Delrin® acetal resin. The combination results in improved wear characteristics along with strength, toughness, dimensional stability and machinability.
FACTS
Chemical designation
POM-H (Polyacetal (Homopolymer))
Color
brown
Density
1.5 g/cm3
MAIN FEATURES
excellent wear properties
low static friction
high mechanical load capacity
good machinability
TARGET INDUSTRIES
conveyor technology
automotive industry
business machines
heavy duty industry
printing machines
packaging and paper machinery
Key Properties
NSF Standard 61 Compliant for Rod
Excellent Wear Characteristics
Self Lubricating
Low Coefficient of Friction (COF)
Maximum Unmodified Toughness
Superior Load Bearing Characteristics
Limitations
Wear Resistance in Dry Environments
Poor Resistance to Strong Acids and Alkalies
Larger Cross Sections are prone to Centerline Porosity
Applications
Automotive Industry
Bushings & Bearings
Business Machines
Conveyor Technology
Heavy Duty Industry
Packaging and Paper Machinery
Printing Machines
Thrust Washers
Wear Components
Wear Strips
Typical Properties of Delrin ® 100 AF Blend 13% PTFE-filled Acetal
| Description | Value | ||
| Material Type | Semi-Crystalline Thermoplastic | ||
| Chemical Name | POM Polyoxymethylene Acetal Homopolymer | ||
| Trade Name | DELRIN®100 AF Blend | ||
| Additives | 13 % PTFE fibers | ||
| Color | Brown to Dark Brown | ||
| Manufacturer | Ensinger | ||
| PHYSICAL | |||
| Property | Test | Unit of Measure | Value |
| Density | ASTM D792 | g/cm³ | 1.5 |
| ASTM D792 | lb/in³ | 0.054 | |
| Water Absorption, 24 hrs, Immersion | ASTM D570 | % by wt. | 0.12 |
| MECHANICAL | |||
| Property | Test | Unit of Measure | Value |
| Tensile Strength | ASTM D638 | psi | 8,100 |
| Tensile Modulus | ASTM D638 | psi | 310,000 |
| Flexural Strength | ASTM D790 | psi | 12,700 |
| Flexural Modulus | ASTM D790 | psi | 485,000 |
| Compressive Strength | ASTM D695 | psi- 10% Deformation | 12,500 |
| Compressive Modulus | ASTM D695 | psi | 250,000 |
| Hardness | ASTM D785 | Rockwell M | Rockwell M79 |
| IZOD Impact-Notched | ASTM D256 | ft-lb/in | 1 |
| Static Coefficient of Friction | (Dry vs Steel) Static | N/A | 0.2 |
| Dynamic Coefficient of Friction | (Dry vs Steel) Dynamic | NA | 0.19 |
| THERMAL | |||
| Property | Test | Unit of Measure | Value |
| Coefficient of Linear Thermal Expansion | ASTM D696 | x 10-5 in./in./°F | 5 |
| Heat Deflection Temp | ASTM D648 | °C at 264 psi | 118 |
| ASTM D648 | °F at 264 psi | 244 | |
| Melting Point Temp | ASTM D3418 | °C | 175 |
| ASTM D3418 | °F | 347 | |
| ASTM D3418 | °F | 347 | |
| Max Continuous Operating Temp | °C | 85 | |
| °F | 185 | ||
| Minimum Operating Temp | °C | -50 | |
| °F | -58 | ||
| Flammability Rating | UL94 | NA | HB |
